85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power

85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power
85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power 85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power 85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power 85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power

Large Image :  85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: According to customer demand
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month
Detailed Product Description
Feed Size: ≤180 Mm Output Size: ≤10mm
Capacity: 30-150 T/h Motor Power: 37-132kw
Rotor Speed: 860-590r/min Dimension: Different Model
High Light:

85% High Efficiency Fine Crusher

,

5mm High Efficiency Fine Crusher

,

85% fine cone crusher

High Efficiency Fine Crusher 85% output below 5mm lower motor power

Iron Ore Mining Machine And Mining Equipment Fine Crusher

High efficiency fine crusher is the most effective and reliable gravel machine. Our fine crusher suitable for crushing granite, basalt, limestone, river gravel, cement clinker, quartz, iron ore, bauxite and other minerals. Also the fine crusher could apply to artificial Sand, highway, railway, water conservancy, airport, construction, cement, refractory, metallurgical and other industries for the production of superior quality stone.

85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power 0

Working principle

When the Fine Crusher is working, materials are crushed primarily in the first crushing chamber by the high speed moving rotor against the hammer, and then enter the secondary chamber for fine crushing, at last, the final materials are discharged.

85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power 185% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power 2

Features

1. Feeding size: 120mm-200mm

2. More than 85% of output below 5mm

Even particle size small, higher output, more durable plate hammer

4. lower motor power, don’t need thirdly crushing

5. Simple structure, easy maintenance and stable running

85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power 3



Model Feed Size Output Size Capacity Motor Power Rotor speed Dimension
(mm) (mm) (t/h) (kw) (r/min) (m)
800*400 ≤120 ≤10 30-40 37-45 860 2.1*1.4*1.7
800*600 ≤180 ≤10 40-50 45-55 860 2.1*1.62*1.7
800*800 ≤180 ≤10 50-70 45-55 860 2.1*1.84*1.96
1010*1010 ≤180 ≤10 60-75 55-75 720 2.1*1.84*1.96
1200*1000 ≤180 ≤10 100-110 90-110 590 2.45*1.6*1.96
1200*1200 ≤180 ≤10 120-150 110-132 590 3*2.16*2.5
