536R/MIN Mineral Ore Dressing Equipment Flotation Machine

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

536R/MIN Mineral Ore Dressing Equipment Flotation Machine

536R/MIN Mineral Ore Dressing Equipment Flotation Machine
536R/MIN Mineral Ore Dressing Equipment Flotation Machine 536R/MIN Mineral Ore Dressing Equipment Flotation Machine 536R/MIN Mineral Ore Dressing Equipment Flotation Machine 536R/MIN Mineral Ore Dressing Equipment Flotation Machine 536R/MIN Mineral Ore Dressing Equipment Flotation Machine

Large Image :  536R/MIN Mineral Ore Dressing Equipment Flotation Machine

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: regular packing
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 300 sets per month
Detailed Product Description
Keywords: Flotation Machine Flotation Machine: 200-540
Rotational Speed (r/min): 191-536 Capacity (m³/min): 0.06-12
Main Motor Power (kw): 1.5-22kw Scraper Motor Power (kw): 0.55-2.2
Size (mm): Different Model Usage: Selecting The Valuable Mine From Gangue
Application: Mineral Ore Dressing Plants Feature: Large Air-absorption Capacity And Low Energy Consumption
High Light:

536R/MIN Mineral Ore Dressing Equipment

,

536R/MIN Flotation Machine

,

Flotation Mineral Ore Dressing Equipment

Mineral Ore Dressing Plants Good Performance Flotation Machine

Application of Flotation Machine



Flotation machine are mainly used in mineral ore dressing plants, selecting the valuable mine from gangue. It is applicable for the separation of numerous of mineral ores, such as fluorite and talc, gold ore, copper ore, iron ore and zinc ore and so on.

536R/MIN Mineral Ore Dressing Equipment Flotation Machine 0

Working principle



The impellers are driven through V-belt transmission, which brings centrifugal effect to form the negative pressure. On the one hand, the flotation machine inhales sufficient air to mix with ore slurry. On the other hand, it stirs ore slurry and mix with medication to form the mineralized forth. To adjust the height of the flashboard to control the liquid level and make the useful froth scraped by loam board.

536R/MIN Mineral Ore Dressing Equipment Flotation Machine 1

Features of Flotation Machine



1. Large air-absorption capacity and low energy consumption

2. Optimistic structure design & Excellent performance

3. Reasonable circulation of mineral slurry

4. Automatic control Easy to adjust

536R/MIN Mineral Ore Dressing Equipment Flotation Machine 2

Technical Parameters



SF Model Diameter (mm) Rotational Speed (r/min) Capacity (m³/min) Main Motor   Scraper Motor   Size (mm)
        Model Power (kw) Model Power(kw)
SF0.15 200 536 0.06-0.18 Y100-6 1.5 Y80L-4 0.55 500×500× 600
SF0.37 296 386 0.2-0.4 Y90L-4 1.5 Y80L-4 0.55 700×700× 750
SF-1.2 450 312 0.6-1.2 Y32M-6 5.5 90S-4 1.1 1100×1100× 1100
SF-2.8 550 268 1.5-3.5 Y180L-6 11 Y100L6 1.5 1700×1600× 1150
SF-4 650 220 2-4 Y200L-8 15 Y100L6 1.5 1850×2050× 1200
SF-8 760 191 4-8 Y250M8 30 Y100L6 1.5 2200×2900× 1400
SF-10 760 191 5-10 Y250M8 30 Y100L6 2.2 2200×2900× 1700
JIF-4 410 305 2-5 Y160L-6 11 Y100L6 1.5 1600×2150× 1250
JIF-8 540 233 4-10 Y200L26 22 Y100L6 1.5 2200×2900× 1400
JIF-10 540 233 4-12 Y200L26 22 Y100L6 2.2 2200×2900× 1700
