Product Details:
Payment & Shipping Terms:
|
| Type: | Rotary Drying Equipment | Certification: | ISO/CE |
|---|---|---|---|
| Power: | As Details | Weight: | As Details |
| Dimension: | As Details | Warranty: | 1 Year |
| Key Selling Point: | Energy Saving | Application: | Chemical Industry |
| After-sales Service: | Online Support, Video Technical Support, Field Installation | Material: | Steel |
| High Light: | 40TPH Cement Rotary Kiln,1.8×14m Cement Rotary Kiln,1.8×14m Oxidized Pellet Rotary Kiln |
||
high quality oxidized pellet rotary kiln from China manufacturer
Oxidized Pellet Kiln Description:
Our oxidized pellet rotary kiln is typically designed to provide high-quality pellets for blast-furnace ironmaking. And it's able to help to improve productivity, as well as to protect environment.
Our oxidized pellet rotary kiln mainly consists of rotating part, supporting part, kiln head cover, sealing parts of kiln head and end, and burning device.
The guard boards of kiln mouth employ individual cast, thus easy to install. And they have good heat-resistant quality as well as wear-resisting property.
ZTIC Oxidized Pellet Rotary Kiln technical characteristics:
Kiln body is made of high quality composed of carbon steel or alloy steel plate and automatic welding;
Tyre,Support Roller,Open gear adopts alloy cast steel；
Sliding bearing with large gap not scraping tile bearing;
Transmission device adopts hard tooth surface reducer, flexible diaphragm coupling, dc motor;
Adopts hydraulic gear wheel;
Preheater scales were used respectively to veiw of kiln head, and cylinder pressure tight seal;
A slow drive device.
Established in 1958, ZTIC Co., Ltd is a professional manufacturer of oxidized pellet rotary kiln in China. Besides oxidized pellet rotary kiln, we also provide customers worldwide with bauxite rotary kiln, titanium dioxide rotary kiln, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. With the certification of ISO9000 and CE, our products have been well received by customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Japan, South Korea, Bengal, Pakistan, Turkey, Burma, Vietnam, South Africa, Columbia, Bolivia, etc. If you're interested in our rotary kiln, please contact us freely.
Oxidized Pellet KilnTechnical Parameters:
| Name | Specification | Capacity (t/h) | Power(KW) |
| Rotary dryer | Φ1.8×14m | 30-40 | 22 |
| Φ2×14m | 40-60 | 22 | |
| Φ2.2×12m | 50-55 | 55 | |
| Φ2.2×16m | 40-45 | 75 | |
| Φ2.4×18m | 45-60 | 95 | |
| Φ3×20m | 160 | 220 | |
| Φ3.6×24m | 150 | 250 | |
| Φ4.2×25m | 250 | 315 | |
| Disc balling machine | Φ3.6m | 18-20 | 22 |
| Φ4.2m | 28-33 | 55 | |
| Φ4.5m | 35-45 | 75 | |
| Φ5.5m | 40-60 | 110 | |
| Φ6m | 65-70 | 110 | |
| Chain grate heater | 1.6×24m | 100,000-200,000tons/year | 15 |
| 2.4×24m | 300,000tons/year | 11 | |
| 2.8×36m | 400,000-600,000tons/year | 18.5 | |
| 2.8×42m | 400,000-600,000tons/year | 18.5 | |
| Rotary kiln | Φ2.2×18m | 10-12 | 45 |
| Φ2.5×20m | 18-25 | 30 | |
| Φ2.8×22m | 30-34 | 90 | |
| Φ3×28m | 40 | 90 | |
| Φ3.5×30m | 50 | 220 | |
| Φ4×30m | 90 | 190 | |
| Φ4.7×35m | 140-180 | 315 | |
| Φ5×35m | 165-202 | 315 | |
| Φ6.1×40m | 226-335 | 315 | |
| Oxidized pellet rotary kiln | 20m 2 | 40 | 7.5×2 |
| 30m 2 | 40-60 | 11×2 | |
| 40m 2 | 90 | 15×2 | |
| 50m 2 | 112 | 15×2 | |
| 69m 2 | 130-160 | 11×2 | |
| 121m 2 | 270-304 | 15×2 | |
| 128m 2 | 280-315 | 18.5×2 | |
| Sintering pellet cooler | 140m 2 | 302 | 11×2 |
Note: Specific parameters should refer to particular contract.
