Product Details:
Payment & Shipping Terms:
|
| GENERATOR SETS MODEL: | XG-300GF | RATED POWER（KW）: | 313 |
|---|---|---|---|
| MANUFACTURE OF ENGINE: | CUMMINS MACHINERY | MODEL: | NTA855-G2A |
| COOLING SYSTEM: | Closed Circulation,Forced Water Cooling,Large-Flux Water Pump | STARTING WAY: | STARTED BY 24V ELECTRICITY |
| GOVERNING METHOD: | ELECTRONIC GOVERNOR | DISPLACEMENT（L）: | 14 |
| NUMBER OF CYLINDERS-BORE*STROKE(MM): | 6×140×152 | COMPRESSION RATIO: | 14.5:1 |
| TOTAL CAPACITY OF OIL（L）: | 38.6 | ||
| High Light: | 313kw Electronic Speed Governor,NTA855-G2A Electronic Speed Governor,XG-300GF Electronic Speed Governor |
||
Electronic Governor XG-300GF NTA855-G2A 313kw with Cummins engine factory
CUMMINS series generating -sets are persisting on integration and maximum efficiency for its products, as well as generating-sets are the optimum choice for users not only in standby field but also in prime field .Its excellent performance and incomparable reliability are leading to the best power solutions in power generating field.
Cummins engine structure characteristics
(1) Most of them are equipped with the company's unique PT fuel system (except Series B and C).
(2) all use Ω combustion chamber.
(3) the CAM follower is roller type.
(4) most of the fuel and oil channels are drilled in the cylinder block and cylinder head.
(5) wet cylinder liner, cylinder liner after phosphating treatment.
(6) the crankshaft is forged with alloy steel, and the journal is inductively quenched.
(7) The first ring grooves of all pistons are provided with nickel alloy cast iron inserts to improve ring groove life.
CUMMINS diesel generator sets choose dongfeng/chongqing CUMMINS engine, which has the advantages of high reliability, easy maintenance, long running time and long working time, etc., and has won the favor of customers in ports, railways, industrial and mining enterprises and other industries.As a foreign investor in China's engine industry, Cummins owns Dongfeng Cummins Engine Co., Ltd. (producing B, C and L series) and Chongqing Cummins Engine Co., Ltd. (producing M, N and K series), and manufactures to Cummins' global quality standards.Cummins global service network, to provide reliable service for customers.
Chongqing cummins diesel generator company is the world's design, production and sales of diesel engines and compressed natural gas engine enterprises.Cummins has invested more than 140 million US dollars in China. As a foreign investor in China's engine industry, Cummins has eight joint venture and wholly owned manufacturing enterprises in China, among which Dongfeng Cummins produces B, C and L series diesel engines, and Chongqing Cummins produces M, N and K series diesel engines.The products meet the standards of ISO 3046, ISO 4001, ISO 8525, IEC 34-1, GB1105, GB/T 2820, CSH 22-2, VDE 0530 and YD/T 502-2000 "Technical Requirements for Diesel Generators for Communication" and so on.
B, C, L series Dongfeng Cummins diesel generator set
· Dongfeng Cummins B, C and L series engines are adopted, with inline 4-cylinder and 6-cylinder models.Displacement of 3.9L, 5.9L, 8.3L, 8.9L, etc., power coverage range of 24KW-220KW, advanced technology, reliable performance.
M, N, K series chongqing cummins diesel generator set
· Chongqing Cummins M, N and K series engines, including in-line 6 cylinder, V-12 cylinder, V-16 cylinder and other models.Displacement of 14L, 18.9L, 37.8L, etc.Advanced technology, reliable performance, long running time, can be stable operation in a variety of environments, and easy maintenance and maintenance.Its power range is 200KW-1200KW, mainly used in mining, power generation, ships, rail cars and petroleum machinery.
CUMMINS diesel generator sets choose dongfeng/chongqing CUMMINS engine, which has the advantages of high reliability, easy maintenance, long running time and long working time, etc., and has won the favor of customers in ports, railways, industrial and mining enterprises and other industries.As a foreign investor in China's engine industry, Cummins owns Dongfeng Cummins Engine Co., Ltd. (producing B, C and L series) and Chongqing Cummins Engine Co., Ltd. (producing M, N and K series), and manufactures to Cummins' global quality standards.Cummins global service network, to provide reliable service for customers.
| item | description |
| serious | M,N,K,B,C,L |
| engine certificate |
ISO 3046,ISO 4001,ISO 8525,IEC 34-1,GB1105,GB/T 2820,CSH 22-2,VDE 0530 ,YD/T 502-2000 |
CUMMINS diesel generator sets choose dongfeng/chongqing CUMMINS engine, which has the advantages of high reliability, easy maintenance, long running time and long working time, etc., and has won the favor of customers in ports, railways, industrial and mining enterprises and other industries.As a foreign investor in China's engine industry, Cummins owns Dongfeng Cummins Engine Co., Ltd. (producing B, C and L series) and Chongqing Cummins Engine Co., Ltd. (producing M, N and K series), and manufactures to Cummins' global quality standards.Cummins global service network, to provide reliable service for customers.
CUMMINS diesel generator sets choose dongfeng/chongqing CUMMINS engine, which has the advantages of high reliability, easy maintenance, long running time and long working time, etc., and has won the favor of customers in ports, railways, industrial and mining enterprises and other industries.As a foreign investor in China's engine industry, Cummins owns Dongfeng Cummins Engine Co., Ltd. (producing B, C and L series) and Chongqing Cummins Engine Co., Ltd. (producing M, N and K series), and manufactures to Cummins' global quality standards.Cummins global service network, to provide reliable service for customers.
Chongqing cummins diesel generator company is the world's design, production and sales of diesel engines and compressed natural gas engine enterprises.Cummins has invested more than 140 million US dollars in China. As a foreign investor in China's engine industry, Cummins has eight joint venture and wholly owned manufacturing enterprises in China, among which Dongfeng Cummins produces B, C and L series diesel engines, and Chongqing Cummins produces M, N and K series diesel engines.The products meet the standards of ISO 3046, ISO 4001, ISO 8525, IEC 34-1, GB1105, GB/T 2820, CSH 22-2, VDE 0530 and YD/T 502-2000 "Technical Requirements for Diesel Generators for Communication" and so on.
B, C, L series Dongfeng Cummins diesel generator set
· Dongfeng Cummins B, C and L series engines are adopted, with inline 4-cylinder and 6-cylinder models.Displacement of 3.9L, 5.9L, 8.3L, 8.9L, etc., power coverage range of 24KW-220KW, advanced technology, reliable performance.
M, N, K series chongqing cummins diesel generator set
· Chongqing Cummins M, N and K series engines, including in-line 6 cylinder, V-12 cylinder, V-16 cylinder and other models.Displacement of 14L, 18.9L, 37.8L, etc.Advanced technology, reliable performance, long running time, can be stable operation in a variety of environments, and easy maintenance and maintenance.Its power range is 200KW-1200KW, mainly used in mining, power generation, ships, rail cars and petroleum machinery.
| GENERATOR SETS MODEL | XG-300GF | |
| POWER | RATED POWER(KW) | 313 |
| MAX POWER(KW) | 343 | |
| MANUFACTURE OF ENGINE | CUMMINS MACHINERY | |
| MODEL | NTA855-G2A | |
| TYPE | IN-LINE,VERTICAL,WATER-COOLED,SIX-STROKE | |
| TURBO PRESSURIZATION | ||
| COOLING SYSTEM | CLOSED CIRCULATION,FORCED WATER COOLING,LARGE-FLUX WATER PUMP | |
| STARTING WAY | STARTED BY 24V ELECTRICITY | |
| GOVERNING METHOD | ELECTRONIC GOVERNOR | |
| DISPLACEMENT(L) | 14 | |
| NUMBER OF CYLINDERS-BORE*STROKE(MM) | 6×140×152 | |
| OIL CONSUMPTION | FUEL(g/KW·h) | ≤206 |
| OIL(g/KW·h) | ≤1.5 | |
| COMPRESSION RATIO | 14.5:1 | |
| TOTAL CAPACITY OF OIL(L) | 38.6 | |
| ALTERNATOR | SINGLE-BEARING,BRUSHLESS,SELF-EXCITATION,AVR AUTOMATIC VOLTAGE REGULATOR,Ｈ LEVEL INSULATION,IP21～IP23DEGREE OF PROTECTION | |
| GENERATOR SETS | CURRENT(A) | 540 |
| NOISE DB(A) | ≤100 | |
| STRUCTURE FEATURES | HIGH STRENGTH CAST-IRON WITH WEARABILITY AND CORROSION RESISTANCE | |
| MAIN TECHNICAL PARAMETER | 50Hz,1500RPM,400V/230V,POWER FACTOR 0.8,THREE-PHASE FOUR-WIRE,SILENT | |
| NET WEIGHT(KG) | 4330 | |
| OVERALL DIMENSIONS(MM) (L×W×H) | 4230×1460×2150 | |
