| Name: | High-efficiency Probability Screen | Model: | GS1015 |
|---|---|---|---|
| Capacity: | 60-350(t/h) | Keywords: | Screen |
| Screening Size Range(mm): | 0.075-20 | Installed Power: | 2.25-30 Kw |
| Number Of Layers: | 2-6 | Classification: | Ore Dressing Equipment |
| High Light: | Probability Screen Low Energy Consumption,30kw Probability Screen,30kw Vibratory Screening Equipment |
||
Probability Screens Of Ore Dressing Equipment With Low Energy Consumption
1. Product overview of Probability Screen for Ore Dressing Equipment
The GS series of high-efficiency probability screens are developed and manufactured by multi-disciplinary comprehensive technology principles such as probability, physics, statistics, etc. It is a new type of green environmental protection screening equipment, widely used in refractory materials, building materials, metallurgy, abrasives, chemicals, and food The fine screening of medium and fine materials in industries such as, medicine and other industries is especially suitable for multi-stage screening and dry material operations in refractory materials, machine-made sand, dry mortar, coal, chemical industries and other industries.
2. Technical parameters of Probability Screen for Ore Dressing Equipment
|
Model |
Number of layers |
Screen size(m) |
Screening size range(mm) |
Installed power(kw) |
Processing capacity(t/h) |
Max. size(m) |
|
GS1015 |
2-6 |
1.0*1.4 |
0.075-20 |
2.25-3.7 |
60 |
2.5*1.6*2.0 |
|
GS1025 |
2-6 |
1.0*2.5 |
0.15-30 |
7.4-9 |
100 |
4.6*1.8*3.8 |
|
GS1625 |
2-6 |
1.5*2.5 |
0.2-50 |
9-14 |
160 |
4.7*2.2*3.8 |
|
GS2125 |
2-6 |
2.0*2.5 |
0.2-50 |
9-14 |
210 |
4.8*2.8*3.8 |
|
GS2625 |
2-6 |
2.5*2.5 |
0.3-50 |
22-30 |
260 |
4.9*3.5*3.8 |
|
GS3125 |
2-6 |
3.0*2.5 |
0.3-50 |
24-30 |
350 |
5.0*3.7*3.8 |
Probability Screen for Ore Dressing Equipment
(1) The processing capacity varies with factors such as the type of screening material, particle size, gradation, moisture content, density and other factors;
(2) The typical processing capacity in the table is the reference value of limestone with a particle size of 13mm, a density of 1.6t/m³, and a moisture content of less than 2%;
(3) Under the same conditions, the time required for screening materials with probability screens is only 1/3~1/6 of that of ordinary vibrating linear screens, and the processing capacity per unit area of the screen is 5-10 times larger than that of ordinary vibrating linear screens ；
(4) The manufacturer reserves the right to revise the technical parameters, please contact our company for details.
3. Application of probability screen in complete refractory processing system
In order to meet the national requirements of high efficiency, energy saving and environmental protection, our company combines the actual situation of the crushing and processing of refractory materials (such as bauxite, quartz sand, magnesia, etc.) at home and abroad, and based on years of research, optimization and improvement and practice, we have launched a Brand-new refractory material crushing production and processing technology system. The system not only covers a small area, can be continuously produced around the clock, intelligent control, convenient maintenance, environmental protection, but also through optimization and improvement of configuration, system matching, etc., make this product in terms of technical performance, reliability, energy saving and environmental protection. Industry leading level.
Probability Screen for Ore Dressing Equipment
Probability Screen for Ore Dressing Equipment
