Product Details:
Payment & Shipping Terms:
|
| Product Name: | Thrust Cylindrical Roller Bearing | Gear Type: | Thrust Cylindrical Roller Bearing |
|---|---|---|---|
| Maximum Temperature: | 200 ~ 300 ℃ | Outside Diameter: | 0 ~ 1,500 Mm |
| Type: | Slewing Ring Bearing | Maximum Speed: | 50-10000mm |
| Axial Dynamic Load Capacity: | 1,000 ~ 3,000,000 N | Axial Static Load Capacity: | 2,000 ~ 6,000,000 N |
| High Light: | 1500Mm cylindrical roller thrust bearing,Cylindrical Thrust Roller Bearings,OEM Thrust Roller Bearings |
||
OEM Custom China Manufacturer Cylindrical Thrust Roller Bearings
1. Introduction of thrust bearing
Thrust cylindrical roller bearing and thrust tapered roller bearing are rolling bearings used to withstand axial loads and are widely used in mechanical engineering fields.
2. Introduction of thrust cylindrical roller bearings
Thrust cylindrical roller bearing is a kind of rolling bearing used to bear axial load. It consists of an inner and outer cylinder, a roller and a cage, wherein the rollers are cylindrical, they are arranged along the axis, and roll on the inner and outer cylinders. It can withstand large axial loads, and has high stiffness and load capacity.
3. Thrust cylindrical roller bearing characteristics
The main characteristics of thrust cylindrical roller bearings are that they can bear large axial loads, and have high stiffness and load capacity. Compared with other types of thrust bearings, the axial size of thrust cylindrical roller bearings is smaller, so it is more convenient in terms of installation and maintenance. In addition, the thrust cylindrical roller bearing also has higher rotation accuracy and lower friction loss.
4. Thrust cylindrical roller bearing application
Thrust cylindrical roller bearings are widely used in various industrial machinery and equipment, such as steel, mining, lifting, power, water pumps and ships. They play an important role in large mechanical equipment, such as generators, hydraulic machines, wind turbines, ship propellers and so on.
Slewing Ring Bearing And Thrust Cylindrical Roller Bearing
5. Parameter table of thrust cylindrical roller bearing and thrust tapered roller bearing:
(1) Parameter table 1
| Parameter | Thrust cylindrical roller bearing | Thrust tapered roller bearing |
| Rolling element shape | Cylindrical | Conical |
| Inside and outside circular shape | Cylindrical surface | Conical surface |
| Bear axial load | √ | √ |
| Bear radial load | × | √ |
| The cone Angle is adjustable | × | √ |
| The axial size is small | √ | × |
| Scope of application | Heavy machine tools, metallurgical equipment, mining machinery, etc | Steel, mining, lifting, electricity, water pumps and ships |
(2) Parameter table 2
| Parameter | Description |
| Axial dynamic load capacity | 1,000 ~ 3,000,000 N |
| Axial static load capacity | 2,000 ~ 6,000,000 N |
| Maximum speed | 500 ~ 2,000 rpm |
| Maximum temperature | 200 ~ 300 ℃ |
| Precision class | P0, P6, P5, P4 |
| Size range | Inside diameter 20 ~ 1,200 mm,Outside diameter 40 ~ 1,500 mm |
Slewing Ring Bearing And Thrust Cylindrical Roller Bearing
Slewing Ring Bearing And Thrust Cylindrical Roller Bearing
Slewing Ring Bearing And Thrust Cylindrical Roller Bearing
After-sales service
LUOYANG ZHONGTAI INDUSTRIES able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS
LUOYANG ZHONGTAI INDUSTRIES’s Field Service Engineers are trained specifically in the LUOYANG ZHONGTAI INDUSTRIES brand group products but are capable of undertaking the servicing of other OEM brands. Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time. LUOYANG ZHONGTAI INDUSTRIES also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.
