Product Details:
Payment & Shipping Terms:
|
| Specifications (mm): | 1800*2000 | Feed Opening (mm): | 1260*2040 |
|---|---|---|---|
| Max.feeding Side Length (mm): | 300-700 | Capacity (t/h): | 30-800 |
| Power (kw): | 37-710kw | Total Weight (t): | 12-83.21 |
| Dimensions: | Different Model | Advantage: | High-efficiency |
| Keyword: | Crushing Machine | Product Name: | Impact Crusher |
| High Light: | 800 Tph Stone Crusher Machine,30Tph Stone Crusher Machine,800Tph impact stone crusher |
||
| Model | Specifications (mm) |
Feed opening (mm) |
Max.feeding side length (mm) |
Capacity (t/h) |
Power (kw) |
Total weight (t) |
Dimensions (L×W×H) (mm) |
| PF-1007 | Φ1000×700 | 400×730 | 300 | 30-70 | 37-45 | 12 | 2330×1660×2300 |
| PF-1010 | Φ1000×1050 | 400×1080 | 350 | 50-90 | 45-55 | 15 | 2370×1700×2390 |
| PF-1210 | Φ1250×1050 | 400×1080 | 350 | 70-130 | 110 | 17.7 | 2680×2160×2800 |
| PF-1214 | Φ1250×1400 | 400×1430 | 350 | 100-180 | 132 | 22.4 | 2650×2460×2800 |
| PF-1315 | Φ1320×1500 | 860×1520 | 500 | 130-250 | 220 | 27 | 3180×2720×2620 |
| PF-1520 | Φ1500×2000 | 830×2040 | 700 | 300-550 | 315-400 | 50.6 | 3959×3564×3330 |
| PF-1820 | Φ1800×2000 | 1260×2040 | 700 | 600-800 | 630-710 | 83.21 | 4400×3866×4009 |
