Product Details:
Payment & Shipping Terms:
|
| Name: | Compound Cone Crusher | Cavity Type: | Fine |
|---|---|---|---|
| Capacity: | 180-350 T/H | Feeding Size(MM): | ≤130MM |
| Classification: | Stone Crusher Machine | Discharging Size(MM): | 20-45 Mm |
| Warranty: | 12 Months | Type: | ZX1650S-X |
| Stroke: | 25 Mm | Power: | 250 Kw |
| High Light: | stone crushing equipment,stone crusher plant |
||
ZX Series Compound Cone Crusher Of Stone Crusher Machine For Mining
1. Product introduction of ZX Series Compound Cone Crusher Of Stone Crusher Machine
ZX compound cone crusher has hydraulic cavity cleaning, hydraulic adjustment discharge port function, moving fixed tooth plate replacement without packing, reduce equipment management and maintenance costs.
2. Product parameters of ZX Series Compound Cone Crusher Of Stone Crusher Machine
| Model | Cavity Type | Stroke (mm) |
Max.Feeding Size(mm) | Discharging Opening Adjusted Scope(mm) | Capacity (t/h) |
Motor power(kw) | Machine reference weight (t) |
| ZX1650C2-D | Coarse | 34 | 300 | 35-65 | 280-610 | 250 | 35 |
| ZX1650C-D | Coarse | 34 | 260 | 30-60 | 265-580 | 250 | 35 |
| ZX1650Z-D | Medium Coarse | 34 | 240 | 25-50 | 240-550 | 250 | 35 |
| ZX1650S-X | Fine | 28 | 130 | 20-45 | 180-350 | 250 | 35 |
| ZX1400C-D | Coarse | 30 | 235 | 30-60 | 210-530 | 220 | 25 |
| ZX1400Z-D | Medium Coarse | 30 | 215 | 25-50 | 200-500 | 220 | 25 |
| ZX1400Z-X | Medium Coarse | 25 | 180 | 22-45 | 180-475 | 220 | 25 |
| ZX1400S-X | Fine | 25 | 100 | 19-40 | 130-260 | 220 | 25 |
| ZX1200C-D | Coarse | 22 | 180 | 19-50 | 110-250 | 132 | 16 |
| ZX1200S-X | Fine | 15 | 80 | 16-40 | 80-180 | 132 | 16 |
3. Product advantages of Compound Cone Crusher Of Stone Crusher Machine
(1) It only takes 2 hours to replace the tooth plate, reducing the downtime.
(2) Large crushing ratio, large spindle eccentricity, large feed port, small discharge port, so the output per unit time is larger.
(3) The speed is improved on the basis of the old spring cone machine, so that the power utilization rate is high and the cost is reduced.
(4) More crushing chamber type: ZX series compound cone crusher cavity type special design, users can choose according to the requirements of high crushing efficiency, uniform product particle size, good stone shape, rolled mortar wall and broken wall wear uniform and long service life of the crushing chamber type;
(5) Dry oil seal dust proof: ZX series compound cone crusher dust proof seal structure is unique, reliable sealing effect, its performance is far better than the traditional water seal, extends the replacement cycle of lubricating oil and the service life of bearings, bearing bush, gear and other parts, suitable for use in areas with little water or water shortage,
(6) Low cost of daily operation and maintenance. The material selection and structure design are reasonable, and the service life is long. The crushing moment arm is long, reduces the sliding bearing, high crushing efficiency, uniform particle size of broken products, and reduces the cycle load; Hydraulic adjustment, locking and cavity cleaning system easy to operate, improve the operation rate of equipment; Low power consumption and reasonable distribution.
FQA
Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts.
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.
Q:Delivery time :
A: Parts lead time 1-2months, machines 2-3months.
Q:Payment terms :
A: Accept payment type: T/T, L/C, Western union,Cash. 30% deposit when signed contract. Full payment paid before shipping.
Q: Quality warranty?
A: Guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.
Q: After sales service?
A: We can supply technical guide for machines running test and parts maintenance if end user needs.
