| Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Energy & Mining | Condition: | New |
|---|---|---|---|
| Type: | Selective Coal Crusher | Application: | Coal Crusher For Coal Plant |
| Motor Type: | AC Motor | Capacity(t/h): | 80-300 Tph |
| Dimension(L*W*H): | 2600x5000 Selective Coal Crusher | Weight: | 40.9 T |
| Warranty: | 1 YEAR | After-sales Service Provided: | Video Technical Support, Online Support, Field Installation, Commissioning And Training |
| Coal Crusher: | Selective Coal Crusher | Effective Diameter Of The Drum: | 2600mm |
| Effective Length Of Rotor: | 5000mm(Including To Screen Section) | Cylinder Slope: | D=0°(horizontal) |
| Drum Rotation Speed: | 13.7rpm | Max Feed Size: | 300mm |
| Discharge Size: | <50mm | Material Falling Number: | 8-9 |
| Capacity: | 300tph | Weight(With No Load): | 40.9 Ton |
| Port: | QingDao,ShangHai,TianJin | ||
| High Light: | CE Stone Crusher Machine,Coal Plant Stone Crusher,Raw coal impact stone crusher |
||
The equipment for raw coal roughing integrates breaking, screening and dressing, smashes large coal blocks through strength difference of gangue and coal, and separates coal and gangue through barrel wall gap, and is widely used for top crushing of large and medium coal preparation plants. CIC HMC reasonably designs sieve pores for it, reducing blockage and improving efficiency
Φ2600X5000 Selective Coal Crusher parameters
| 1, Effective diameter of the drum | 2600mm |
| 2, Effective Length Of Rotor | 5000mm(Including to screen section) |
| 3,c ylinder slope | d=0°(horizontal) |
| 4, drum rotation speed | 13.7rpm |
| 5, Max Feed Size | 300mm |
| 6, Discharge size | <50mm |
| 7, Material falling number | 8—9 |
| 8, capacity | 300tph(Amount of raw coal) |
| 9, motor | model:JO2-72-6 power:22kw Speed:970rpm Numbe :2 |
| 10, reducer | model:PM650-VI-3z 1 set PM650-VI-4 1 set Speed ratio =15.75 |
| 11, Weight(With no load) | 40.9 ton |
| 12, Dimensions:L* W * H | 9580×3410×4910MM |
Φ2400X3200 Selective Coal Crusher parameters
| 1, Effective diameter of the drum | 2200mm |
| 2, Effective Length Of Rotor | 3200mm (Including to screen section) |
| 3, cylinder slope | d=0°( horizontal ) |
| 4, drum rotation speed | 13.7 rpm |
| 5, Max Feed Size | 300mm |
| 6 ,Discharge size | <50mm |
| 7, Material falling number | 8—9 |
| 8, capacity | 120tph( Amount of raw coal ) |
| 9, motor | Model:Y2 200L-6 Power:18.5KW Speed :rpm Numbe :2 |
| 10 reducer | Model :KD80-A 1 set KD80-B 1 set Speed ratio =15.75 |
| 11, Weight(With no load) | 22.9T |
| 12, Dimensions:L* W * H | 9608×2854×4180mm |
Φ2000×3200 Selective Coal Crusher parameters
| 1, Effective diameter of the drum | 1800mm |
| 2, Effective Length Of Rotor | 3200mm (Including to screen section) |
| 3, Cylinder slope | d=0°( horizontal ) |
| 4, Drum rotation speed | 10.8 rpm |
| 5, Max Feed Size | 300mm |
| 6, Discharge size | ≤50mm |
| 7, Material falling number | 8—9 |
| 8, capacity | 80Tph ( Amount of raw coal ) |
| 9, motor | Model:Y160M1-4 Power:11KW Speed:1460Rpm Numbe :2 set |
| 10, Reducer | Model:KDK08 1 set Nuber: 2 set Speed ratio :i=24.92 |
| 11, Weight(With no load) | 15.2T |
| 12, Dimensions:L* W * H | 9608×2140×2730mm |
Aftersales service
LUOYANG ZHONGTAI INDUSTRIES able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS
LUOYANG ZHONGTAI INDUSTRIES’s Field Service Engineers are trained specifically in the LUOYANG ZHONGTAI INDUSTRIES brand group products but are capable of undertaking the servicing of other OEM brands.
Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time.
LUOYANG ZHONGTAI INDUSTRIES also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.
Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts.
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.
Q:Delivery time:
A: parts lead time 1-2months, machines 2-3months.
Q:Payment terms:
A: Accept payment type: T/T, L/C, Western union,Cash.
30% deposit when signed contract. Full payment paid before shipping.
Q: Quality warranty?
A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.
Q: After sales service?
A: we can supply technical guide for machines running test and parts maintenance if end user needs.
