Product Details:
Payment & Shipping Terms:
|
| Shape: | Spur | Condition: | New |
|---|---|---|---|
| Warranty: | 1.5 Years | Applicable Industries: | Manufacturing Plant, Construction Works , Energy & Mining |
| After Warranty Service: | Video Technical Support, Online Support | Local Service Location: | Viet Nam, Indonesia, Australia, Argentina |
| Showroom Location: | None | Material: | Steel |
| Product Name: | Ring Gear, Girth Gear | Certificate: | ISO9001:2015 |
| Color: | Customers' Demand | Application: | Large Cement Ball Mill And Rotary Kiln |
| Standard Or Nonstandard: | Standard | Processing: | Casting |
| Item: | Machining Parts | Port: | QingDao,ShangHai,TianJin |
| High Light: | Cement Ball Mill Girth Gear,120 MT girth gear,ISO9001:2015 ring gear |
||
| Product Name | Steel girth spur gear |
| Weight | Max 120 MT single piece |
| Applications | industries |
| Module Range | 10 Module to 70 Module. |
| Diameter | Min 100 mm to16000 mm. |
| Weight | Max 120 MT single piece. |
| Gear Cutting Capacity | 100mm diameter to 16000mm diameter,10Module to 70Module |
| External teeth | |
| Maximum diameter | 16000 mm |
| Toothed face width | 1700 mm |
| Maximum module | 45 by hob |
| Maximum module | 65 gear finishing cutter |
| Internal teeth | |
| Maximum Diameter | 6500 mm |
| Maximum module | 25.4 |
| Toothed face width | 400 mm |
|
Standards/Certificates
• UNI EN ISO • AWS • ASTM • ASME • DIN |
Spur Gear And Ring Gear
