High Pressure 1000TPH Roller Press In Cement Plant Full Speed Full Material

Large Image : High Pressure 1000TPH Roller Press In Cement Plant Full Speed Full Material

Product Details:

Place of Origin:	China
Brand Name:	ZTIC
Certification:	ISO/CE
Model Number:	According to customer demand

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiable
Packaging Details:	Standard shipping packaging
Delivery Time:	30 days
Payment Terms:	L/C, T/T
Supply Ability:	30 sets per month

Contact Now

Detailed Product Description

Product Name:	Roller Press	Keywords:	Grinding Equipment
Model:	Different Model	Capacity(t/h):	105-1000
Motor (kW):	2315-21400	Linear Velocity(m/s):	1.36-1.7
Usage:	Cement Grinding Equipment	Grinding Way:	Roller Grinding
Quality:	ISO/CE	Application:	Powder Grinding
Highlight:	1000TPH Roller Press In Cement Plant , 1.7M/s Roller Press In Cement Plant , 1000TPH roller press cement mill

Roller press high pressure for Cement Grinding Plant full speed full material

Roller press Structural Features

Roller press consists of frame, two roller system, transmission device, torque support, roller cover, feeding device, hydraulic (pressurization) system, main bearing lubrication system, dry oil lubrication system, electrical system and other parts.

(1) increasing production: in grinding roller machine installed in the system, the high voltage load by double roller diameter is passed to the grinding material layer, the interaction between the most energy is used in the material extrusion, sound energy and heat energy produced by the friction material can be converted into material deformation, the deformation, tearing, crushing, can give full play to the potential power to make the grinding equipment, increase production of up to 50-100%, the total energy consumption can be reduced by 20% - 30%, improved the production efficiency of the whole system.
(2) reduce power consumption: grind materials with roller press. Not only the particle size of the material is greatly reduced, but the bond function index is also significantly reduced, which greatly improves the grinding condition of the subsequent mill and significantly reduces the unit power consumption of the whole grinding system. The total power consumption of the grinding system can be significantly reduced. Compared with the traditional grinding method, the energy saving is 25-50%, and the annual electricity saving benefit is considerable.
(3) saving investment: compared with tube mill, roller mill with the same production capacity is simple in structure, small in size, light in weight and small in space, which can save civil construction investment and facilitate the transformation of the original grinding system. In addition, the operation and maintenance of roller press is also very simple.
(4) good working environment: the material is continuously and stably crushed in the extrusion roller cover, and the harmful dust is not easy to be diffused. At the same time, because there is almost no impact, the noise of the roller is much lower than that of the tube mill.
(5) easy to develop: the traditional tube mill is restricted by processing, transportation, heat treatment and other conditions, and the upsizing of tube mill is greatly restricted. The grinding system of matching roller press solves the problem well. So that the grinding system to large - scale development into a reality.

Specification

Model	Capacity(t/h)	Motor (kW)	Linear velocity(m/s)
100-60	105~150	2×(315)	1.36
120-45	100~140	2×220	1.38
120-80	240~300	2×450	1.31
140-80	340~400	2×560	1.47
140-100	400~480	2×630	1.48
140-110	500~600	2×710	1.6
140-140	550~630	2×800	1.48
180-170	900~1000	2×1400	1.7
