90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor

90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor
90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor 90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor 90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor 90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor 90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor

Large Image :  90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: According to customer demand
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month
Detailed Product Description
Product Name: Apron Feeder Keyword: Conveyor
Chute Dimension Mm: 3800*950 Max. Feeding Size Mm: 750
Feeding Capacity T/ph: 400-560 Power Kw: 11
Weight Kg: 5352 Power Type: Electric
Certificate: ISO/CE Feature: High Efficiency
High Light:

600 Tph Conveying Hoisting Machine

,

600 Tph Apron Feeder Conveyor

,

90tph Apron Feeder Conveyor

90-600 tph high conveying capacity wide application range apron feeder conveyor



The apron feeder conveyor is a series of conveying equipment that carries a solid moving material to support the bulk solid material by a series of metal phosphor plates supported on the roller chain. Phosphor plate conveyors are available in three types: horizontal, inclined and horizontally inclined. The working principle is basically the same. The movement of materials is formed by the phosphor plate. The slat conveyor mechanism is simple, has a wide application range, has a high conveying capacity, low running resistance, convenient installation and maintenance, and long service life. It can not only be transported horizontally, but also can be conveyed obliquely; it can be multi-point feeding, and the equipment process layout is flexible.



90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor 0

90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor 1
Applications
Mainly applied in feeding for conveyor bucket type lifting machine crusher ball mill and also used in automatic control system to realize the automation of production Process.
Feeding for coarse crusher screening fine materials to increase crusher capacity
For transporting ferrous or non-ferrous metal ores building materials but sticky wet material
Widely used in metallurgy mining mineral Processing building materials chemical industry and other industries.
Technical Parameter



Model Chute Dimension mm Max. Feeding Size mm Feeding Capacity t/ph Power kw Weight kg
ZSW-380×95 3800×950 500 96-160 11 4082
ZSW-420×110 4200×1100 580 120-240 15 4149
ZSW-490×960 4900×960 500 120-240 15 5351
ZSW-490×110 4900×1100 630 120-280 15 5352
ZSW-590×110 5900×1100 630 350-500 22 6130
ZSW-600×130 6000×1300 750 400-560 22 7800



90-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor 290-600 Tph Conveying Hoisting Machine Wide Application Range Apron Feeder Conveyor 3
