Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height

Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height
Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height

Large Image :  Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: According to customer demand
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month
Detailed Product Description
Item: Continuous Mechanical Handling Equipment Product Name: Belt Conveyor
Belt Width (mm): 500-1000 Length(m): Max.25
Belt Speed (m/s): 0.8-2.0 Lifting Height: Adjustable
Slope Angle: 0-30 Capacity (m3/h): 50-550
Feature: Simple Structure And Easy Installation Application: Mining
High Light:

1000Mm Mobile Belt Conveyor

,

500Mm Mobile Belt Conveyor

,

1000Mm lightweight portable conveyors

coal industrial 500-1000 mm mobile belt conveyor Cheap cost and long working life



Mobile belt conveyor is a kind of continuous mechanical handling equipment with high efficiency, good safety and good mobility. Mainly used for short-distance transport, handling of bulk material and the product one-piece weight less 100kg on loading and unloading stations which are often changed, such as the port, terminal, station, coal yard, warehouse, building site, sand quarry, farm and so on. It can be divided into lift and not lift type, the running of belt is driven by electric-roller, and the whole lifting and running are non-motorized.

Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height 0

Features
1.Simple structure and easy installation.
2.Low rate of breakdown and adapt to different use condition.
3.Various design form can meet different industries.
4.Cheap cost and long working life.
5.Easy move with special wheels.

Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height 1Coal Industrial 500-1000 Mm Mobile Belt Conveyor Adjustable Lifting Height 2

The mobile belt conveyor widely used in mining,gravel field, metallurgy, building materials,chemical industry,mineral processing,coal mining and other industries.It can convey bulk material like coal,cement,sand,cereal etc.And can convey lump material,such as rock,also it can convey 50kg bags.



Model Belt Width (mm) Length(m) Belt Speed (m/s) Lifting Height Slope Angle Capacity (m³/h)
DY-500 500 Max.20 0.8-2.0 adjustable 0-30 50-140
DY-650 650 Max.20 0.8-2.0 adjustable 0-30 100-250
DY-800 800 Max.25 0.8-2.0 adjustable 0-30 170-350
DY-1000 1000 Max.25 0.8-2.0 adjustable 0-30 270-550

Notes:The parameter above is just for reference,More models pls inquiry us directly.We accept customization.
