8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System

8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System
8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System 8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System 8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System 8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System 8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System

Large Image :  8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: According to customer demand
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month
Detailed Product Description
Product Name: Screw Conveyor Diameter(mm): 108-500
Conveying Angle: 0-60 Power(kw): 1.5-11
Capacity(t/h): 8-55 Usage: Conveying Powder, Granule Or Small Block Materials
Feature: Conveyor Has Big Transport Capacity, Long Distance Available. Speed: Adjsutable(1-60 M/min)
Keyword: Packing Screw Conveyer Equipment Function: Electric Conveyor Machine
High Light:

55 Tph Industrial Screw Conveyor

,

8TPH Industrial Screw Conveyor

,

55 Tph Screw Conveyor System

8-55 tph Screw conveyor continuous and highly efficient operation



Application:
The screw conveyor is widely used for conveying powder, granule or small block materials, usually it could be used with the suit sieving machine.

8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System 08-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System 1
Features:
1.The motor reducer could be installed on the top or the bottom.
2.Conveyor has big transport capacity, long distance available.
3.Stable and controllable start, continuous and highly efficient operation.
4.The conveying could be the level or the inclined.
5.The blade could be entity spiral or belt spiral.

8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System 2
Technical parameters :

Diameter(mm) conveying angle Power(kw) Capacity(t/h)
108 0-60 1.5-2.2 8
159 0-60 2.2-3 16
219 0-45 3-4 30
273 0-45 4-5.5 40
300 0-30 5.5-7.5 45
400 0-30 7.5-11 50
500 0-30 7.5-11 55
