Dia 1000mm 200rpm Powder Grinding Mill Machine Ultrafine Powder Mill

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

Dia 1000mm 200rpm Powder Grinding Mill Machine Ultrafine Powder Mill

Dia 1000mm 200rpm Powder Grinding Mill Machine Ultrafine Powder Mill
Dia 1000mm 200rpm Powder Grinding Mill Machine Ultrafine Powder Mill

Large Image :  Dia 1000mm 200rpm Powder Grinding Mill Machine Ultrafine Powder Mill

Product Details:
Place of Origin: Henan, China
Brand Name: CITIC LK
Certification: ISO/CE
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set/Sets
Price: $1,000,000.00 - $3,000,000.00 / Set
Packaging Details: Simple packaging
Supply Ability: 500 Set/Sets per Year
Detailed Product Description
Product Name: Powder Grinding Mill Condition: New
Motor Type: AC Motor Capacity(t/h): 0.5-12
Dimension(L*W*H): 18x4.6x8.6m Weight: 38t
Power Supply: AC 380V, 50HZ Layer Number: 4
Ring Diameter: 1000mm Main Shaft Speed: 180-200 R.p.m
Max. Input Size: 20mm Output Size: 5-47 Micron
High Light:

200rpm Powder Grinding Mill Machine

,

Dia 1000mm Powder Grinding Mill Machine

,

Dia 1000mm Ultrafine Powder Mill

Powder Grinding Mill Machine Ultrafine powder mill



Product Description

HGM Series Micro Powder Grinder specializes in grinding fine and superfine powders of non-flammable, non-explosive and brittle materials with Moh’s hardness under 6, moisture below 6%, such as calcite, chalk, limestone, dolomite, kaolin, bentonite, talc, mica, magnetite, illite, pyrophyllite, vermiculite, sepiolite, attapulgite, rectorite, diatomite, barite, gypsum, alunite, graphite, fluorite, rock phosphat, Kalium ore, pumice, etc, totally more than 100 kinds of materials.

Main Specification:

Model HGM80 HGM90 HGM100 HGM100L HGM125
Ring Diamater(mm) 800 900 1000 1000 120
Ring Number(layer) 3 3 3 4 4
Roller Number(piece) 21 24 27 36 44
Main Shaft Speed(r.p.m) 230-240 200-220 180-200 180-200 135-155
Input Size(mm) 0-20 0-20 0-20 0-20 0-20
Finished Size(micron/mesh) 5-47(325-2500) 5-47(325-2500) 5-47(325-2500) 5-47(325-2500) 5-47(325-2500)
Capacity(t/h) 0.5-4.5 0.6-6.5 0.7-7 1-8.5 1.5-12
Overall Dimension(LxWxH,m) 13.9x4x6.2 14.7x4.8x7.2 18x4.6x8.6 18x4.6x8.6 14x9x10.25
Power(KW) 123-143 168.35 221.6 243.95 344.4



Our Services

Aftersales service
CITIC Heavy Industries is your business partner in the After Market.

CITICIC  able to provide:

1.    ENGINEERED SPARES -  DESIGN AND MANUFACTURING

2.    LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES

3.    HUGE MACHINE SHOP CAPABILITIES

4.    TRAINING PROGRAMMES

5.    PREVENTATIVE MAINTENANCE PROGRAMS

6.    PREVETATIVE MAINTENANCE SERVICES

7.    COMPREHENSIVE MAINTENANCE PROGRAMS

 CITIC’s Field Service Engineers are trained specifically in the CITIC brand group products but are capable of undertaking the servicing of other OEM brands.

 Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time.

 CITICIC also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.

FAQ

Quality Control

Physical & Chemical Identification Center

CITICIC owns a professional testing and metrology institute which provides advanced testing methods such as nondestructive testing, industrial chemical analysis, metallographic testing and analysis, mechanical testing, sample preparation, meter/length measurement, weighing apparatus verification, and weighman inspection. Our metrology institute has taken a leading role in China.

CITICIC owns nearly two hundred types of advanced testing equipment, nine different measurement standards and nearly twenty types of world-class testing equipment which have been imported from international locations such as Germany, Japan, USA, UK and Belgium.
