Ball Mill Machine 23r/min 0.22TPH Mining Ore Grinding Mill With Large Capacity

Large Image : Ball Mill Machine 23r/min 0.22TPH Mining Ore Grinding Mill With Large Capacity

Product Details:

Place of Origin:	China
Brand Name:	ZTIC
Certification:	ISO/CE
Model Number:	According to customer demand

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiable
Packaging Details:	Standard shipping packaging
Delivery Time:	30 days
Payment Terms:	L/C, T/T
Supply Ability:	30 sets per month

Contact Now

Detailed Product Description

Speed (r/min):	57.3-23	Ball Loading(t):	0.6-40
Feeder Size(mm):	0-40	Capacity(t/h):	0.22-1.07
Power(Kw):	15-320	Weight(kg):	3150-73365
High Light:	0.22TPH Mining Ore Grinding Mill , 23r/Min Mining Ore Grinding Mill , 23r/Min Ball Mill Machine

Hot Sale Ball Mill Machine Mining Grinding Mill with large capacity

Mining Grinding Mill With Factory Price

Ball mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and

non-ferrous metal, glass ceramics,our ball mill can save electricity 10-15%,we make Ceramic and rubber ball mill.


			Model

			speed

			(r/min)

			ball Loading(t)

			Feeder size(mm)

			Capacity(t/h)

			Power(Kw)

			Dimension(mm)

			Weight(kg)

			LZMQ0612

			57.3

			0.6

			20

			0.1-0.6

			15

			3360/1230/1320

			3150

			LZMQ07518

			52.4

			1.19

			0-40

			0.22-1.07

			18.5

			5262/1924/1797

			5060

			LZMQ0909

			47.8

			0.96

			0-40

			0.22-1.07

			18.5

			4150/2300/2015

			4920

			LZMQ0912

			41.6

			0.9

			0-40

			0.3~0.9

			11

			3843/1850/1400

			4210

			LZMQ0918

			41.6

			1.66

			0-40

			0.37~1.8

			22

			5300/1200/1100

			5600

			LZMQ0930

			41.6

			3.48

			0-40

			0.6~5.5

			30

			5943/1850/1400

			7770

			LZMQ1224

			35.1

			4.8

			0-40

			0.35-8.2

			55

			5540/2300/1850

			10020

			LZMQ1228

			35.1

			4.6

			25

			1.9~4.8

			45

			5940/2300/1850

			10935

			LZMQ1232

			35.1

			5.3

			25

			2.2~5.5

			45

			6340/2300/1850

			11230

			LZMQ1244

			35.1

			7.3

			25

			3.0~7.5

			55

			7540/2300/1850

			13210

			LZMQ1324

			30.2

			4.5

			25

			1.5~3.5

			37

			5035/2370/1880

			10210

			LZMQ1328

			30.2

			5.2

			25

			2.0~4.5

			45

			5435/2370/1880

			11290

			LZMQ1334

			30.2

			6.5

			25

			2.2~5.0

			75

			6035/2370/1880

			13117

			LZMQ1524

			30.7

			7.0

			25

			2.8~6.5

			55

			6830/2930/2060

			15430

			LZMQ1530

			30.7

			10.0

			0-25

			2.2-12

			95

			7430/2930/2060

			16843

			LZMQ1533

			30.7

			10.0

			25

			4.0~9.0

			95

			7730/2930/2060

			17849

			LZMQ1536

			30.7

			11.0

			25

			4.5~10.0

			95

			8030/2930/2060

			18649

			LZMQ1540

			30.7

			11.11

			25

			4.8~10.5

			110

			9030/2930/2060

			19103

			LZMQ1542

			30.7

			12.5

			25

			5.0~11.0

			110

			8630/2930/2060

			19330

			LZMQ1545

			30.7

			13.5

			25

			5.5~13.5

			130

			8930/2930/2060

			20000

			LZMQ1557

			30.7

			17.0

			25

			7.0~15.5

			155

			10130/2930/2060

			23597

			LZMQ1563

			30.7

			19.0

			25

			8.0~17.0

			155

			10730/2930/2060

			24390

			LZMQ1830

			25.04

			13.0

			25

			3.0~17.0

			130

			8456/3654/2250

			29490

			LZMQ1834

			25.04

			14.0

			25

			3.3~20.0

			155

			8856/3654/2250

			30390

			LZMQ1836

			25.04

			15.0

			25

			4.0~21.5

			155

			9056/3654/2250

			31600

			LZMQ1840

			25.04

			17.0

			25

			4.5~24

			155

			9456/3654/2250

			32700

			LZMQ1856

			25.04

			21.9

			25

			7~35

			245

			10956/3754/2250

			39290

			LZMQ1864

			25.04

			27.0

			25

			8.0~40.0

			210

			10220/3754/2250

			42440

			LZMQ1870

			25.04

			27.3

			25

			8.5~45.0

			320

			10820/3754/2250

			45590

			LZMQ2122

			23.8

			15.0

			25

			3.0~22.0

			155

			7775/4060/3400

			38793

			LZMQ2130

			23.8

			20.0

			25

			4.0~30.0

			180

			8475/4060/3400

			41965

			LZMQ2430

			23.0

			20

			25

			6~75

			280

			9170/5005/3970

			59850

			LZMQ2436

			23.0

			26.6

			25

			6.5~82

			280

			9770/5005/3970

			63684

			LZMQ2440

			23.0

			30

			25

			7.0~92

			320

			9966/5005/3970

			67984

			LZMQ2445

			23.0

			32.5

			25

			8~100

			320

			10575/5005/3970

			72284

			LZMQ2460

			23

			40

			25

			10~120

			320

			11175/5005/3970

			73365

Tag:

80 Mesh Ming ball Mill,

195 tph Mining Ball Mill,

500000 TPY Cement Vertical Mill

Contact Details

Luoyang Zhongtai Industrial Co., Ltd.

Contact Person: Mr. David

Tel: 86-18637916126

Other Products

Vertical Small Scale Overflow High Pressure Raymond Mill and raymond mill factory price

Applicable Industries: Manufacturing Plant, Construction works , Energy & Mining

Local Service Location: None

Showroom Location: None

Condition: New

Energy Saving Continuous 215T Air Swept Mining Ball Mill Ore Grinding Mill

Applicable Industries: Manufacturing Plant, Machinery Repair Shops, Energy & Mining

Condition: New

Type: Ball Mill

Motor Type: AC Motor

AC Motor Large Capacity Integral Drive Tube Grinding Mill And Cement Ball Mill

Applicable Industries: Manufacturing Plant, Machinery Repair Shops, Energy & Mining

Condition: New

Type: Ball Mill

Motor Type: AC Motor

Circulating Bed Boilers ISO CE/Ceramic Mining Ball Mill Ore Grinding Mill

Applicable Industries: Manufacturing Plant, Energy & Mining

Local Service Location: Viet Nam, Indonesia, Australia, Argentina

Showroom Location: None

Condition: New

Cylindrical PLC Control Ore Wet Stone Grinding Mining Ball Mill

Applicable Industries: Manufacturing Plant, Construction works , Energy & Mining

Condition: New

Type: Ball Mill

Motor Type: AC Motor

Model	speed (r/min)	ball Loading(t)	Feeder size(mm)	Capacity(t/h)	Power(Kw)	Dimension(mm)	Weight(kg)
LZMQ0612	57.3	0.6	20	0.1-0.6	15	3360/1230/1320	3150
LZMQ07518	52.4	1.19	0-40	0.22-1.07	18.5	5262/1924/1797	5060
LZMQ0909	47.8	0.96	0-40	0.22-1.07	18.5	4150/2300/2015	4920
LZMQ0912	41.6	0.9	0-40	0.3~0.9	11	3843/1850/1400	4210
LZMQ0918	41.6	1.66	0-40	0.37~1.8	22	5300/1200/1100	5600
LZMQ0930	41.6	3.48	0-40	0.6~5.5	30	5943/1850/1400	7770
LZMQ1224	35.1	4.8	0-40	0.35-8.2	55	5540/2300/1850	10020
LZMQ1228	35.1	4.6	25	1.9~4.8	45	5940/2300/1850	10935
LZMQ1232	35.1	5.3	25	2.2~5.5	45	6340/2300/1850	11230
LZMQ1244	35.1	7.3	25	3.0~7.5	55	7540/2300/1850	13210
LZMQ1324	30.2	4.5	25	1.5~3.5	37	5035/2370/1880	10210
LZMQ1328	30.2	5.2	25	2.0~4.5	45	5435/2370/1880	11290
LZMQ1334	30.2	6.5	25	2.2~5.0	75	6035/2370/1880	13117
LZMQ1524	30.7	7.0	25	2.8~6.5	55	6830/2930/2060	15430
LZMQ1530	30.7	10.0	0-25	2.2-12	95	7430/2930/2060	16843
LZMQ1533	30.7	10.0	25	4.0~9.0	95	7730/2930/2060	17849
LZMQ1536	30.7	11.0	25	4.5~10.0	95	8030/2930/2060	18649
LZMQ1540	30.7	11.11	25	4.8~10.5	110	9030/2930/2060	19103
LZMQ1542	30.7	12.5	25	5.0~11.0	110	8630/2930/2060	19330
LZMQ1545	30.7	13.5	25	5.5~13.5	130	8930/2930/2060	20000
LZMQ1557	30.7	17.0	25	7.0~15.5	155	10130/2930/2060	23597
LZMQ1563	30.7	19.0	25	8.0~17.0	155	10730/2930/2060	24390
LZMQ1830	25.04	13.0	25	3.0~17.0	130	8456/3654/2250	29490
LZMQ1834	25.04	14.0	25	3.3~20.0	155	8856/3654/2250	30390
LZMQ1836	25.04	15.0	25	4.0~21.5	155	9056/3654/2250	31600
LZMQ1840	25.04	17.0	25	4.5~24	155	9456/3654/2250	32700
LZMQ1856	25.04	21.9	25	7~35	245	10956/3754/2250	39290
LZMQ1864	25.04	27.0	25	8.0~40.0	210	10220/3754/2250	42440
LZMQ1870	25.04	27.3	25	8.5~45.0	320	10820/3754/2250	45590
LZMQ2122	23.8	15.0	25	3.0~22.0	155	7775/4060/3400	38793
LZMQ2130	23.8	20.0	25	4.0~30.0	180	8475/4060/3400	41965
LZMQ2430	23.0	20	25	6~75	280	9170/5005/3970	59850
LZMQ2436	23.0	26.6	25	6.5~82	280	9770/5005/3970	63684
LZMQ2440	23.0	30	25	7.0~92	320	9966/5005/3970	67984
LZMQ2445	23.0	32.5	25	8~100	320	10575/5005/3970	72284
LZMQ2460	23	40	25	10~120	320	11175/5005/3970	73365
