Efficient Fine Powder 16-18 TPH Cement Ball Mill For Cement Industry

efficient fine powder grinding tool cement ball mill for cement industry

ZTIC has produced cement grinding mills fitting the requirement of cement industrial development with cement design institutes in Tianjin, Nanjing and Hefei for dozens of years. Our large cement grinding mills have been sold in many domestic cement manufacturers, and exported to Vietnam, Indonesia, Rwanda and other countries. We have first-rate cement grinding mill research and design team, perfect test and inspection means and excellent large Cement Ball Mill manufacturing equipment and manufacturing technology, and have formed a complete Cement Ball Millexperimental research, design, manufacture, detection and service system.

Ball grinding mill is mainly used to grind the clinker and raw materials in cement industry and also can be applied in metallurgy, chemical, electric power and other industries to grind all kinds of ores. Cement mill is not only suitable for over-flow grinding, but also applicable for cyclic close-flow grinding together with powder collector.

Ball grinding mill

Ball mill is an efficient tool for fine powder grinding. The Ball Mill is used to grind many kinds of mine and other materials, or to select the mine. Ball mill is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine.

Feature:
♦The cylindrical mill adopts the driving type edge-driving, center-driving, edge-driving with multi-point meshing, etc; driven by asynchronous motor +reducer +pinion and gear as well as synchronous motor.
♦Generally supported by static-dynamic pressure bearing on both ends. Fuuly closed self-aligning 120º osculation rocker bearing is used. Also single or double slipper staic- dynamic bearings can be used. The bush is made by NC machine.
♦ The large open gear is designed using AGMA standard, Equipped with reliably sealed gear housing and grease ahtomatic spraying lubrication system.
The shell is key part of a mill. Carry out finite element analysis on it with computer to ensure the reliable operation;
♦The shell is automatically welded, ultrasonic inspected, wholly annealed and machined by large special machine tools on one chucking; there special seal on static-dynamic connection parts , ch as feed and discharge hoper, trunnion, etc, to prevent oil and slurry leakage;
♦The liner is of wear-resistance material mad by our company, wich has been specially heat-treated, with high hardness and long service life. Also other wear-resistance casting or rubber liner can be used;
♦ There are slow speed drive for medium and large mill;
♦The high and low pressure lubricating station is equipped for medium and large mill;
♦The control and protection system is controlled by PLC.

Ball mill machine technical advantages

1. High capacity and Low consumption: the capacity of SCM series super-micro mill, compared with that of jet mill and mixing mill, has been improved by 40% under the same final fineness and electric power.

2. High fineness and Flexible adjustment: the final fineness can be adjusted from 325 meshes to 2500 meshes according to the requirements, and the fineness can reach D97≤5um.

3. Trustworthy security: there is no rolling bearing and bolt in the mill chamber, therefore, the bearing and sealing elements will not wear out easily, and the bolts will not loose to make damage to the equipment.

4. Clean and environment-friendly: equipped with the pulse filter and sound absorber, the mill reaches the environment-friendly standard of our country and reduces the dust and noise greatly.

Ball grinding mill working principle

Large materials are crushed by Jaw crusher to the needed sizes firstly, then the materials are elevated to storage hopper by bucket elevator, third, the materials are fed into the grinding chamber for grinding by vibrating feeder equably and continuously. The powder after grinding goes upwards together with the airflow, after separating by powder separator, those which can meet the fineness requirement enters into the cyclone powder collector through pipe together with the airflow, and then discharged from the discharge valve as final products. The airflow is sucked into centrifugal blower through wind recycling pipe at the upper part of cyclone powder collector. The mainframe is driven by the speed reducer through the central axis in the mill.

The quincunx stand connected with the upper part of central axis, at the quincunx stand, rollers are set and by which the vibrating pivot formed. Below the quincunx stand and rollers there is shovel system. Materials are fed into the space between rollers and shovels when they are turning, and then be grinded by the pressure produced when rollers are turning, thus powder is made.

Energy saving measures

The editor

The use of advanced grinding process equipment to achieve energy saving

China's domestic vertical mill, roller press has the advantages of high output, energy consumption (power consumption, metal consumption) is small, raw materials, cement and slag grinding system using more methods.Compared with the ordinary ball mill system, vertical mill and roller press can generally increase output by 80% ~ 20% and save electricity by about 30%. Enterprises can achieve energy saving by increasing production and increasing efficiency.If the one-time investment of the enterprise is considered, the existing open flow ball mill system can transform the ordinary ball mill into a high-fine and high-yield mill with screening function (only for the transformation of the grinding body of the internal mechanism of the mill), and the output increase and electricity saving can generally reach about 30%.In addition, using the characteristics of high yield and high fineness of ground cement, it can also achieve the purpose of energy saving by mixing 5% ~ 10% of mixed materials.For the closed circuit system, the equipment can be updated according to its supporting conditions, such as replacing the original centrifugal separator with a more advanced structure and principle of efficient separator or efficient combined separator, which can increase production and save electricity by more than 30%.

The production cost can be reduced by increasing the utilization rate of waste residue

Slag, steel slag, fly ash and other waste slag, after grinding to the specific surface area of 400m2/kg ~ 600m2/kg above, the mixing material can be increased to more than 30%, the calcium carbide slag is used to prepare raw material, the maximum mixing amount can reach 60%;In addition, the waste of calcining cement raw meal production not belongs to the category of grinding, but it is the direction of the cement production and energy saving, fully using the garbage burning technology is now in some cement plant test facilities successfully ignited, and ash can make garbage all be used, low emissions, not only is advantageous to the grinding, also can be reduced by at least 30% ~ 40% of the resources of traditional high fuel costs of production.

Ball grinding mill | Technical parameters
