Product Details:
Payment & Shipping Terms:
|
Name: | Belt Machine | Processing Capacity: | Max 1200 T/h |
---|---|---|---|
Keyword: | Belt Conveyor | Feature: | Large Throughput, Long Conveying Distance |
Condition: | New | Advantages: | Smooth Conveying, Low Noise |
Material: | Steel | Brand: | ZTIC |
Color: | Custom | Type: | Conveying Hoisting Machine |
Warranty: | 12 Months | ||
High Light: | Belt Conveyor Conveying Hoisting Machine,Belt Conveyor In Mining,Belt Conveyor In Metallurgy |
Conveying Hoisting Machine Belt Machine Belt Conveyor Used In Mining, Metallurgy
1. Product introduction of belt conveyor
The belt conveyor manufactured by Luoyang Mining Machinery Factory can transport various materials economically and effectively. It has the characteristics of large throughput, long conveying distance, smooth conveying, low noise, simple structure, convenient maintenance, less energy consumption, standardized components and so on. Widely used in mining, metallurgy, chemical, casting, building materials and other industries of transportation and production lines and hydropower station construction sites and other production departments.
2. Product parameters
Main technical parameters of belt conveyor:
Belt width (mm) | Belt length/power | Conveying speed(r/s) | Processing capacity(t/h) | ||
Ⅰ(L/kW) | Ⅱ(L/kW) | Ⅲ(L/kW) | |||
B400 | ≤12/1.5 | 12-20/2.2-4 | 20-25/3.5-7.5 | 1.3-1.6 | 40-80 |
B500 | ≤12/3 | 12-20/4-5.5 | 20-30/5.5-7.5 | 1.3-1.6 | 80-190 |
B650 | ≤12/4 | 12-20/5.5 | 20-30/7.5-11 | 1.3-1.6 | 130-320 |
B800 | ≤6/4 | 6-15/5.5 | 15-30/7.5-15 | 1.3-1.6 | 280-550 |
B1000 | ≤10/5.5 | 10-20/7.5-11 | 20-40/11-12 | 1.3-2 | 440-850 |
B1200 | ≤10/7.5 | 10-20/11 | 20-40/15-30 | 1.3-2 | 660-1200 |
