JKM JKMD Tower Multi Rope Friction Mine Hoist Landing

Multi-rope Friction Mine Hoist -JKM Tower Multi-Rope Friction Mine Hoist,JKMD Landing Multi-Rope Friction Mine Hoist



1. The technical characteristics of mine hoist designed and developed by Luoyang Mining Machinery Factory and Research Institute are:

(1) The use of integral, two-flap type, four-flap type of various types of drum;

(2) Drum rope groove adopts processing spiral rope groove, folding rope groove or wood lining and plastic lining pressed spiral rope groove, steel rope transition device is set between the ropes;

(3) Using cylinder rear disc brake, electro-hydraulic joint control; Hydraulic station can be divided into two types: middle and low pressure and middle and high pressure. There are two kinds of constant braking force electric delay and hydraulic delay two-stage brake in middle and low pressure hydraulic station; Middle and high pressure hydraulic station has two forms of constant deceleration and constant braking torque secondary braking. Hydraulic station can be equipped with pressure sensor, pressure relay;

(4) Spindle and drum are connected by plane friction with large torque;

(5) Signal monitoring device composed of photoelectric encoder, self-leveling machine and low-speed Chilean tachogenerator, with overspeed, overwinding, depth indication failure, brake shoe wear, spring fatigue and other perfect monitoring and protection functions;

Bring console has integral and two forms of separate all adopt the electric meter of integrated light, reliable in performance and new type integral operation handle, and a digital depth indicator and digital and screw type depth indicates the depth indicator system as a whole, has a mesa of industrial TV or computer, printer and other special;

(6) The pulley device adopts integral or two-flap welding structure, supported by rolling bearing and friction liner with POLYvinyl chloride or nylon on the rim;

(7) Can be equipped with mine hoist network control and diagnosis system.



Advantages of Conveying Hoisting Machine

2. Advantages of multi-rope friction type mine hoist:

(1) The load is borne by a number of wire rope, wire rope diameter is small, equipment size is small. That is, under the same diameter specification, the lifting capacity is large;

(2) The wire rope is put on the drum, not affected by the rope capacity, suitable for deep Wells;

(3) small inertia, small energy consumption under the same output;

(4) when the tank is stuck or overrolled, it can slip to avoid breaking the wire rope;

(5) the possibility of wire rope breaking at the same time is small, without anti-drop device;

(6) The same number of left twist and right twist wire rope can be used to offset the loose twist trend, to avoid the pressure of the container ear on the tank channel;



3. Typical product introduction of Conveying Hoisting Machine :

(1) Floor type multi-rope friction mine hoist with the largest diameter:

Jkmd-6.2 ×4 ⅲ multi-rope friction type mine hoist

User: Huaneng Gansu Energy Company Hetaoyu mine auxiliary shaft

Used in auxiliary shaft, lifting materials, personnel, and large trackless rubber wheel vehicle (multi-function vehicle, support carrier), the whole hydraulic support and other large parts;

Diameter of friction wheel: 6.2m

Diameter of pulley: 6.2m

Lifting height: 975m

Diameter of wire rope: 66mm

Maximum static tension: 1700KN

Maximum static tension difference: 340KN

Maximum lifting speed: 11.3m/s

Friction coefficient of liner: 0.25

Motor: TDBS3000-24

3000kW, 1450V, 34.8r/min,

Frequency conversion synchronous machine, Shanghai Electric Machinery Factory

(2) The largest diameter tower multi-rope friction mine hoist:

Jkm-5 ×6 ⅲ multi-rope friction mine hoist

User: Auxiliary shaft of Chahasu Coal Mine, Inner Mongolia, China Power Construction Investment

Diameter of friction wheel: 5m

Guide wheel diameter: 5m

Lifting height: 446.5m

Diameter of wire rope: 52mm

Maximum static tension: 1700KN

Maximum static tension difference: 340KN

Maximum lifting speed: 9.42m/s

Friction coefficient of liner: 0.25

Motor: low speed direct and direct

Variable frequency synchronous motor

3000 kw, 3150 v,

36r/min, Siemens motor

(3) Multi-rope friction mine hoist with maximum diameter and maximum single power:

Jkm-4.7 ×6 ⅲ multi-rope friction hoist

User: Inner Mongolia Yinhong Energy Development Co., LTD. Bojiang Haizi mine main well

Diameter of friction wheel: 4.7m

Guide wheel diameter: 4.7m

Lifting height: 580m

Diameter of wire rope: 47mm

Maximum static tension: 1500KN

Maximum static tension difference: 440KN

Maximum lifting speed: 12m/s

Friction coefficient of liner: 0.25

Motor: TDBS5500-16

Low speed direct link variable frequency synchronous motor

5500 kw, 3150 v,

48.8r/min, Shanghai Electric Machinery Factory

(4) Multi-rope friction mine hoist with maximum diameter and maximum power of each single machine:

Jkmd-5.7 ×4 ⅳ multi-rope friction hoist

User: Main shaft of Zhangji coal mine of Huainan Mining Bureau

Diameter of friction wheel: 5.7m

Guide wheel diameter: 5.7m

Lifting height: M

Diameter of wire rope: 57mm

Maximum static tension: 1500KN

Maximum static tension difference: 440KN

Maximum lifting speed: 14m/s

Friction coefficient of liner: 0.25

Motor: BPT3000-24/3250

Low speed direct frequency motor

3000 kw (2150 V,

40.2r/min, Harbin Electric Machine Factory

(5) Multi-rope friction type mine hoist with the largest lifting height:

Jkm-4.5 ×6 ⅲ multi-rope friction hoist

User: New main shaft of Chengchao Iron Mine of Wisco Mining Group

Diameter of friction wheel: 4.5m

Guide wheel diameter: 4m

Lifting height: 1150m

Diameter of wire rope: 44mm

Maximum static tension: 1400KN

Maximum static tension difference: 400KN

Maximum lifting speed: 12m/s

Friction coefficient of liner: 0.25

Motor: TBP4800-16/3280

Low speed direct frequency motor

4800 kw, 3150 v,

50r/min, Harbin Electric Machine Factory

(6) Floor-type multi-rope friction mine hoist with the largest diameter of wire rope:

Jkmd-6.2 ×4 ⅲ multi-rope friction hoist

User: Huaneng Gansu Energy Company Hetaoyu mine auxiliary shaft

Used in auxiliary shaft, lifting materials, personnel, and large trackless rubber wheel vehicle (multi-function vehicle, support carrier), the whole hydraulic support and other large parts;

Diameter of friction wheel: 6.2m

Diameter of pulley: 6.2m

Lifting height: 975m

Diameter of wire rope: 66mm

Maximum static tension: 1700KN

Maximum static tension difference: 340KN

Maximum lifting speed: 11.3m/s

Friction coefficient of liner: 0.25

Motor: TDBS3000-24

3000kW, 1450V, 34.8r/min,

Frequency conversion synchronous machine, Shanghai Electric Machinery Factory



4. Product parameters of Conveying Hoisting Machine

(1)JKM tower multi-rope friction mine hoist

Model	Guide wheel diameter	Wire rope					Maximum lifting speed	Reducer		Displacement weight of rotating parts (except motor and guide wheel)	Guide wheel displacement weight	Dimensions (L×W×H)	Note
		Maximum static tension	Maximum static tension difference between two wire ropes	Maximum diameter with guide wheels	Maximum diameter without guide wheel	Interval
	m	kN		mm			m/s	Model	Velocity ratio	t	t	m
JKM-1.3×4(Ⅰ)E		100	25		16.5	200	5	XP550	11.5	2.1		6.4×6.5×1.6
JKM-1.6×4(Ⅰ)E		150	40		19.5		8	XP560	7.35 10.5 11.5	4		6.4×7×1.75
JKM-1.85×4(Ⅰ)E		210	60		23		10	XP800		5.8		7×7.5×2.02
JKM-2×4(Ⅰ)E	2	230 180	65 55	20	24		10	XP800		5.7		7×8×2.2	In this table, weights and dimensions do not include micro - drag devices
JKM-2.25×4(Ⅰ)E	2	215	65	22	28		10	XP800		6.5	1.39	7.4×8×2.3
JKM-2.8×4(Ⅰ)E	2.5	335	100	28		250	14	XP1   000		9.1	2.48	8.5×10×2.65
JKM-2.8×4(Ⅱ)E								P2H630		10	2.48	7.5×8.5×2.65
JKM-2.8×6(Ⅰ)E	2.5	500	140	28			14	XP1120		15.8	3.69	8×8.5×2.68
JKM-2.8×6(Ⅱ)E								P2H800		17.8	3.69	7.5×8.5×2.68
JKM-2.8×6(Ⅲ)E										14	3.7	7.5×8×2.7
JKM-3.25×4(Ⅰ)E	3	450	140	32		300	14	XP1120	7.35 10.5 11.5	13.36	2.72	8.9×8.9×2.98
JKM-3.25×4(Ⅱ)E								P2H800		15.74	2.72	8.5×8.7×2.98
JKM-3.5×6(Ⅰ)E	3	790	220	35		300	14	XP1250		22.85	4.06	11.5×9.2×3.15
JKM-3.5×6(Ⅱ)E								P2H900		25.6	4.06	10.5×9.2×3.15
JKM-3.5×6(Ⅲ)E										21	4.06	8×9×3.2
JKM-4×4(Ⅰ)E	3.2	690	180	39.5		300	14	XP1250	7.35 10.5 11.5	18.5	4.1	9×10×3.63
JKM-4×4(Ⅱ)E								P2H900		24.7	4.1	9×10×3.63
JKM-4×4(Ⅲ)E										16	4.1	7.5×9×3.63
JKM-4×6(Ⅲ)E	3.2	1030	270	39.5		300				22	6.5	9×9×3.63
JKM-4.5×6(Ⅲ)E	3.6	1330	340	45		300	16			30	10	12×9.5×3.9
JKM-5×6(Ⅲ)E	4	1600	420	50		300



(2)JKMD Floor type multi-rope friction mine hoist

Model

Head sheave diameter

Wire rope

Maximum lifting speed

Reducer

Displacement weight of rotating parts (except motor and guide wheel)

Head sheave displacement weight

Dimensions (L×W×H)

Note

Maximum static tension

Maximum static tension difference between two wire ropes

Maximum diameter

Interval

m

kN

mm

m/s

Model

Velocity ratio

t

t

m

JKMD-2.25×2(Ⅰ)E

2.25

105

25

22

300

10

ZZP560(2)

11.5

4.83

1.2×2

7.7×9×2.1

In this table, weights and dimensions do not include micro - drag devices

JKMD-2.25×4(Ⅰ)E

215

65

XP800(2)

7.35 10.5 11.5

6.5

2.3×2

6.8×9.5×2.3

JKMD-2.8×2(Ⅱ)E

2.8

165

45

28

XP800(2)

4.911 5.165 5.239

1.528×2

7.8×10×2.65

JKMD-2.8×4(Ⅰ)E

335

95

XP1000(2)

9

3.44×2

8.5×10×2.65

JKMD-2.8×4(Ⅱ)E

P2H800(2)

10.2

3.44×2

7.5×10×2.65

JKMD-3.5×2(Ⅰ)E

3.5

265

70

35

XP1000(2)

12

3.1×2

7×9.5×3.02

JKMD-3.5×4(Ⅰ)E

525

140

13

XP1120(2)

20.6

6.3×2

8.5×9.5×3

JKMD-3.5×4(Ⅱ)E

P2H800(2)

22.8

6.3×2

8×9.5×3.02

JKMD-3.5×4(Ⅲ)E
