Product Details:
Payment & Shipping Terms:
|
| Name: | Special Pearl Sand/Baozhu Sand | Particle Size: | 6-320mesh（φ0.053-3.36mm） |
|---|---|---|---|
| Grain Shape: | Spherical | Thermal Conductivity: | （1200℃）5.27W/M.K |
| Classification: | Mining Machine Spare Parts | Color: | Dark Brown |
| Warranty: | 12 Months | Type: | Precision Casting Special Treasure Bead Sand |
| High Light: | Casting Special Treasure Bead Sand,Mining Machine Special Treasure Bead Sand,Casting Baozhu Sand Mining Machine |
||
Precision Casting Special Treasure Bead Sand / Baozhu Sand Mining Machine Spare Parts
1. Introduction of Baozhu sand products for precision casting Mining Machine Spare Parts
Luoyang Zhongtai Industrial Co., LTD. Baozhu sand production, and complete specifications, from the use of the division, can be divided into the following several, and the corresponding number of the scope of use, users can refer to the use.
Specification 1, lost mold pearl sand: 30-40 mesh, 40 mesh, 30 mesh, 12 mesh, 10-30 mesh, 10-20 mesh, 8-12 mesh,
Specification two, coated sand: 30-50 mesh, 40-70 mesh, 70-140 mesh
Specifications Three, polishing pearl sand: 5-10 mesh, 10-20 mesh, 20-30 mesh
Specifications four, drainage Baozhu sand sand: 20-40 mesh, 30-50 mesh
Specification five, cast steel Baozhu sand 40 mesh,
Specification six, paint bead sand 200 mesh
Specification 7, Baozhu sand powder, more than 200 mesh.
2. Characteristics of Baozhu sand Mining Machine Spare Parts:
(1) The coefficient of thermal expansion is small, the performance can be comparable with zircon sand, with its configuration sand, casting will not produce expansion defects;
(2) The sand is spherical, with good fluidity and good air permeability;
(3) The surface is smooth, the structure is compact, so that the adhesive can cover evenly;
(4) Baozhu sand belongs to neutral materials, acid, alkali adhesives can be used;
(5) Good reuse and regeneration performance, high cost performance;
3. Precision casting special Baozhu sand product parameters Mining Machine Spare Parts
The main indicators of Baozhu sand
| Name | Indicators | Name | Indicators | ||
| 1 | Grain shape | Spherical | 7 | Expansion coefficient | (20-1000℃)6X10 -6/℃ |
| 2 | Color | Dark brown | 8 | Particle size | 6-320mesh(φ0.053-3.36mm) |
| 3 | Refractory temperature | ≥1820℃ | 9 | AL2O3 | 70-85% |
| 4 | Mass density | 1.95-2.05g/cm3 | 10 | SIO2 | ≤15% |
| 5 | True density | 2.9g/cm3 | 11 | TIO2 | ≤1.5% |
| 6 | Thermal conductivity | (1200℃)5.27W/M.K | 12 | PH | 7-8 |
After-sales service
LUOYANG ZHONGTAI INDUSTRIES able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS
LUOYANG ZHONGTAI INDUSTRIES’s Field Service Engineers are trained specifically in the LUOYANG ZHONGTAI INDUSTRIES brand group products but are capable of undertaking the servicing of other OEM brands. Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time. LUOYANG ZHONGTAI INDUSTRIES also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.
