| Condition: | New | Name: | Ceramsite Sand Production Line |
|---|---|---|---|
| Application: | In Building Materials, Horticulture, Food And Beverage, | Model: | Ceramsite Sand Production Line |
| Capacity: | Annual Output Of 20,000-30,000 M3 | Classification: | Ore Grinding Mill |
| Usage: | Downhole Support In Oil Fields | Mainly Includes: | Raw Material Storage Bin, Dust Removal Room |
| Dimension(L*W*H): | Custom | Warranty: | 12 Month |
| High Light: | Ore Grinding Mill Mining Equipments,Ore Grinding Ceramsite Sand Production Line,Mining Ceramsite Sand Production Line |
||
Mining Equipments Of Ceramsite Sand Production Line And Ore Grinding Mill
1. Application fields of ceramsite sand:
Ceramsite sand is an alternative to natural quartz sand, glass ball, metal ball and other medium and low strength proppants, which is mainly used for downhole support in oil fields to increase oil and gas production. Can also be widely used in building materials, horticulture, food and beverage, fire insulation materials, chemical, petroleum and other sectors, a wide range of applications.
2. Main equipment of ceramsite sand production line:
The main equipment for the production of ceramics mainly includes: raw material storage bin, dust removal room, auxiliary equipment for the production of shale ceramics: crusher, screening machine, belt conveyor, feeder, hoist, discharge machine, etc.
Auxiliary equipment for the production of fly ash and clay pottery are: wheel mill, double-shaft mixer, pelleting machine, screening machine, feeding belt machine, etc.
Mining Equipments Of Ceramsite Sand Production Line And Ore Grinding Mill
3. Ceramic sand production line process:
Raw materials (fly ash quantitative admixture) mixed grinding - granulation - burning - stacking - transport (bagging). In order to control the preheating time according to the condition of raw material, it is suitable to use double cylinde rotary kiln in the production of pulverized coal ash pottery, that is, the rotary speed of preheating section and drying section of kiln can be controlled separately. The technological process is: raw material stirring - granulation - screening - sintering - stacking - transportation (bagging). During operation, attention should be paid to prevent the materials from clumping in the kiln and affecting the quality.
4. Ceramsite sand production line advantages:
(1) The process design of the whole ceramic sand production line is more reasonable, the operation process is smooth, and the equipment has a high degree of automation;
(2) The whole set of ceramic sand production line mechanized joint control operation, save labor, and low labor intensity, can save a lot of labor costs for users;
(3) Real-time monitoring of forging and firing parameters of core equipment can fully ensure the firing quality of final products and higher yield;
(4) The whole set of ceramic sand production line has high thermal energy utilization rate, greatly reduced energy consumption, low operation cost, and greatly reduced production cost.
Mining Equipments Of Ceramsite Sand Production Line And Ore Grinding Mill
5. Technical parameters of ceramsite sand production line:
Mining Equipments Of Ceramsite Sand Production Line And Ore Grinding Mill
Main equipment according to different ceramic technology, the main equipment required is shown in Table
| Plastic process of ceramsite sand production line Table 1 |
| Serial number name and model |
| 1 wheel mill 2 pair of roller machine 3 box feeder 4 double-shaft mixer 5 pair of roller pelletizing machine 6 cylinder rotary machine 7 double cylinder rotary kiln 8 cooling machine 9 dust removal equipment 10 coal mill |
| Mud pelleting process of ceramsite sand production line is shown in Table 2 |
| Serial number name and model |
| 1 mud mixer 2 mud pump 3 dual-shaft mixer 4 vibrating filter screen 5 air compressor 6 disc pelleting machine 7 double cylinder rotary kiln 8 cooling machine 9 dust removal equipment 10 coal mill |
