Product Details:
Payment & Shipping Terms:
|
| Product Name: | High Pressure Micro Powder Mill | Model: | MW880 Micro Powder Mill |
|---|---|---|---|
| Belt Feeder Model: | 300*60*1.8M | Diameter (mm): | Φ800 |
| Hammer Crusher Power: | 18.5kw | Elevator Model: | TH200 |
| Classification: | Ore Grinding Mill | Warranty: | 12 Months |
| High Light: | High Pressure Micro Powder Mill,High Pressure Ore Grinding Mill,High Pressure Superfine Grinding Mill |
||
High Pressure Micro Powder Mill Ore Grinding Mill Superfine Grinding Mill
1. Introduction of micro powder grinding mill Ore Grinding Mill
Micro powder grinding mill is an efficient milling equipment which is made by improving fineness classification technology of finished products on the basis of high pressure mill.
2. Application scope of micro powder grinding machine Ore Grinding Mill
Micro powder grinding mill mainly for conventional materials, such as kaolin, limestone, calcite, talc, marble, barite, gypsum, iron oxide red, iron oxide green, aluminum hydroxide, pigment, bentonite, clay, carbon black, such as coal, activated carbon humidity less than 8%, below the mohs hardness at level 6 non flammable material of ultrafine powder processing.
3. Technical Data of micro powder grinding mill Ore Grinding Mill
| Model | MW880 |
| Roller number | 21 |
| Diameter (mm) | Φ800 |
| Ring number | 1 |
| Main unit speed(mm) | 235 |
| Max. feeding size(mm) | 10 |
| Final size (mesh) | 325-2500 |
| Capacity (kg/h) | 4500-400 |
| Overall dimension (m) | 13.9×4×6.5 |
4. Main configuration of micro powder grinding mill Ore Grinding Mill
| No. | Product Name | Spec |
| 1 |
MW880 micro powder grinder |
Main frame(Power:75kw) Separator(Power:18.5kw frequency conversion) Blower(Power:45kw) Cyclone Collector Air Conduit |
| 2 | Hammer crusher |
Model:PC400x600 Power:18.5kw |
| 3 | Elevator |
Model:TH200 Power:3kw |
| 4 | The belt feeder |
Model:300*60*1.8M Power:1.5kw frequency conversion |
| 5 | Party bin | |
| 6 | Piston air compressor |
Model:LGY-2.8/8 Power:15kw |
| 7 | Screw conveyer |
Model:SC219x4m Power:4kw |
| 8 | Packing machine |
Model:JKF-159CH Power:15kw |
| 9 | Electrical control cabinet | Model:Ⅳ |
FQA
Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts.
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.
Q:Delivery time :
A: Parts lead time 1-2months, machines 2-3months.
Q:Payment terms :
A: Accept payment type: T/T, L/C, Western union,Cash. 30% deposit when signed contract. Full payment paid before shipping.
Q: Quality warranty?
A: Guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.
Q: After sales service?
A: We can supply technical guide for machines running test and parts maintenance if end user needs.
