Product Details:
Payment & Shipping Terms:
|
| Type: | Planetary Gear Reducer | Power (KW): | 630-1600 KW |
|---|---|---|---|
| Model: | Steel Planetary Reducer | Rotation Rate: | 34-44 |
| Application: | Manufacturing Plant, Energy & Mining | Port: | QingDao,ShangHai,TianJin |
| Warranty: | 12 Months | Classification: | Gear Reducer Gearbox |
| High Light: | Low Backlash Precision Planetary Reducer,Low Backlash Gear Reducer Gearbox,Precision Planetary Gear Reducer Gearbox |
||
Precision Planetary Reducer With Low Backlash Gear Reducer Gearbox
1. Introduction of high-power reducer and gear reducer gearbox
Since 1970s, our institute has introduced a variety of complete sets of reducer design, manufacturing, installation and maintenance technology from RENK Company of Germany, F.L. Mid-th Company of Denmark, CITROEN of France and other companies. Over the years, we have absorbed advanced technology from SIEMAG, MAAG, DANIELI, KHI and other companies. The advanced technology mentioned above and the new technology developed through improvement and innovation over the years have been integrated into product design and development, forming their own intellectual property rights, developed a number of characteristic technical products, such as 2000kW planetary reducer; The largest 4×5000kN ship lift reducer; The first MB25 hard tooth surface, large torque, multi-point meshing, double split edge transmission device for cement mill in China; And KF300 reducer with the largest φ 1100mm punch in China, its rated output torque is 3000kN. M, the actual up to 4500kN. M.
gear reducer gearbox
2. Technical performance table of ZJA planetary Reducer and gear reducer gearbox
| No. | Power(kw) | Reducer type |
Rotational speed (r/min) |
Rotation rate | Lubrication method | Oil number | Dimensions(mm) | Weight(kg) | |||
| L | B | H | R | ||||||||
| 1 | 630 | ZJA1250 | 750 | 36～44 |
Concentrated circulation lubrication
|
N220~320 Medium load industrial gear oil |
|||||
| 2 | 800 | ZJA1400 | 2135 | 1880 | 530 | 870 | 11000 | ||||
| 3 | 1000 | ZJA1600 | 2270 | 2090 | 570 | 965 | 15000 | ||||
| 4 | 1250 | ZJA1820 | 2430 | 2390 | 670 | 1110 | 22776 | ||||
| 5 | 1600 | ZJA2060 | 600 | 37～41 | |||||||
gear reducer gearbox
gear reducer gearbox
Precision Planetary Reducer With Low Backlash Gear Reducer Gearbox
FQA
Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts.
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.
Q:Delivery time :
A: Parts lead time 1-2months, machines 2-3months.
Q:Payment terms :
A: Accept payment type: T/T, L/C, Western union,Cash. 30% deposit when signed contract. Full payment paid before shipping.
Q: Quality warranty?
A: Guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.
Q: After sales service?
A: We can supply technical guide for machines running test and parts maintenance if end user needs.
