Product Details:
Payment & Shipping Terms:
|
Name: | Active Lime Production Rotary Kiln | Capacity: | 150 T/d |
---|---|---|---|
Type: | K-K Type | Condition: | New |
Fuel: | Coal Gas、 Pulverized Coal | Keyword: | China Rotary Kiln |
Warranty: | 12 Month | Classification: | Metallurgy Machine |
High Light: | Active Lime Production Rotary Kiln,Rotary Kiln Metallurgy Machine,150 T/D Rotary Kiln |
Active Lime Production Rotary Kiln Metallurgy Machine Complete Set System
1. The technical characteristics of complete rotary kiln system for active lime production metallurgy machine are as follows:
(1) The vertical preheater with advanced structure and low pressure loss can effectively improve the preheating effect. The decomposition rate of limestone entering the kiln after preheating can reach 20 ~ 25%, and fine limestone of 10 ~ 50mm can be used;
(2) Reliable rotary kiln at both ends of the combined scale seal, so that the air leakage coefficient is less than 10%, the use of composite refractory lining, to reduce radiant heat loss;
(3) Filling type, zoned ventilation circular or square vertical cooler, the limestone temperature of the cooler is: 80℃ ambient temperature, easy to transport, storage, and can preheat the secondary air into the kiln to more than 700℃, reducing the moving parts and special materials.
2. Product parameters of complete rotary kiln system for active lime production metallurgy machine:
Main parameters of k-K rotary kiln series of active lime production
Designed capacity(t/d) | 150 | 200 | 250 | 300 | 350 | 400 | 500 | 600 | 750 | 800 | 1000 | |
Product |
Light-burned dolomite |
active lime,Light-burned dolomite | active lime,Light-burned dolomite | active lime,Light-burned dolomite | active lime | active lime | active lime | active lime | active lime | active lime | active lime | |
Preheater |
Circular vertical preheater |
Circular vertical preheater |
Circular vertical preheater |
Circular vertical preheater |
Circular vertical preheater |
Circular vertical preheater
|
Circular vertical preheater |
Circular vertical preheater
|
Multilateral vertical preheater
|
Multilateral vertical preheater | Multilateral vertical preheater | |
Rotary kiln | SPEC(m) | Φ2.5×40 | Φ2.8×42 | Φ3×46 | Φ3.2×50 | Φ3.5×54 | Φ3.6×56 | Φ3.8×58 | Φ4×60/ Φ4.2×50 | Φ4.3×58 | Φ4.3×64 | Φ4.8×68 |
Effective volume(m3) | 142 | 190 | 235 | 292 | 390 | 430 | 505 | 575/548 | 670 | 738 | 1005 | |
burning temperature | 1350/1250 | 1350/1250 | 1350/1250 | 1350/1250 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 | |
cooler |
Circular vertical cooler
|
Circular vertical cooler | Circular vertical cooler | Circular vertical cooler | Circular vertical cooler |
Square vertical cooler |
Square vertical cooler | Square vertical cooler | Square vertical cooler | Square vertical cooler | Square vertical cooler | |
fuel | coal gas, pulverized coal |
coal gas, pulverized coal |
coal gas, pulverized coal |
coal gas, pulverized coal |
coal gas, pulverized coal |
coal gas, pulverized coal |
coal gas, pulverized coal |
coal gas, pulverized coal |
coal gas, pulverized coal |
coal gas, pulverized coal |
coal gas, pulverized coal |
|
heat rate (KJ/KgCaO) |
5300/5000 | 5300/5000 | 5300/5000 | 5300/5000 | 5225 | 5225 | 5100 | 5100 | 4810 | 4810 | 4810 |
Based on the introduction of foreign advanced technology through continuous innovation, the k-K type active lime production rotary kiln complete set system developed by Luo Mine has independent intellectual property rights, with nearly ten patent technology; Luo Mining Institute has a first-class research and design team of rotary kiln complete system of active lime production in China, perfect test and testing means, and has formed a technical service system of process design, equipment design, installation and debugging of rotary kiln complete system of active lime production.
Active Lime Production Rotary Kiln Metallurgy Machine Complete Set System
