Product Details:
Payment & Shipping Terms:
|
| Model: | CT60-9 Hydraulic Crawler Excavator | Name: | Crawler Tractor |
|---|---|---|---|
| Oil Cooler Type: | Air Cooled Type | Bucket Capacity Scope M3: | 0.072-0.25 |
| Bucket Teeth Number: | 5 | Bucket Width Mm: | 750 Mm |
| Classification: | Heavy Duty Construction Machinery | Warranty: | 12 Months |
| High Light: | Operating Weight 5820kg Crawler Excavator,Air Cooled Hydraulic Crawler Excavator |
||
Operating Weight 5820kg Heavy Duty Construction Machinery Crawler Excavator
1. Technical Specification Of Heavy Duty Construction Machinery CT60-9 Hydraulic Crawler Excavator
| Engine | Travel System | ||
| Model | Yanmar 4TNV94L | Travel motors |
KYB, Japan; |
| Type | Direct injection, 4 stroke, water cooled, natural intake | Support roller quantities | 2×5 |
| Carrier roller quantities | 2×1 | ||
| No. of cylinder | 4 | Travel shoes | 2X37 |
| Bore and stroke | 94X110(mm) | Travel speed | 2.5/4.0(km/h) |
| Displacement | 3.054L | Drawbar pulling force | 50.4kN |
| Power output | 36.2kw/2100rpm | Gradeability | 70%(300) |
|
Max. torque |
193.2～210.6N.m/1260±100 rpm | Track shoes thickness | 6mm |
| Hydraulic System | Cab & Electrical System | |||||
| Pump
|
KYB, Japan | Cab | installed with silicon oil rubber, adjustable luxurious seat, cold and warm air-conditioning system plus flexible pilot control system | |||
| Type | axial piston pump+ gear pump | |||||
| Max. discharge flow | 160 (L/min) | |||||
| Max. discharge pressure | ||||||
| Boom, arm and bucket | 24.5 MPa | Voltage | 12V | |||
| Travel circuit | 18.6 MPa | Batteries | 1x12V | |||
| Swing circuit | 20.5 MPa | Battery capacity | 80Ah | |||
| Control circuit | 3.9 MPa | Boom, Arm ＆ Bucket | ||||
| Pilot control pump | Gear type | Boom cylinder | Φ110xΦ65xS720-L1095 | |||
| Main control valves | KYB, Japan | Arm cylinder | Φ85xΦ55xS880-L1280 | |||
| Oil cooler | Air cooled type | Bucket cylinder | Φ80xΦ50xS600-L925 | |||
| Swing System | Refilling Capacity & lubrication | |||||
| Swing motor |
KYB, Japan |
Fuel tank | 125 L | |||
| Swing motor type | Axial-piston motor | Cooling system | 15 L | |||
| Brake | Hydraulic oil released | Engine oil | 10.5 L | |||
| Parking brake | Hydraulic disc brake | Hydraulic oil tank | 78 L Tank Oil Level | |||
| Swing speed | 10 r/min | 100 L Hydraulic System | ||||
| Bucket | ||||||
| Type | Backhoe bucket | |||||
| Bucket capacity | 0.22m3 (SAE) | |||||
| Bucket Capacity scope | 0.072-0.25m3 | |||||
| Number of bucket teeth | 5 | |||||
| Bucket width | 750 mm | |||||
| Working Ranges | ||||||
| Boom length | 3050mm | |||||
| A | Max. digging height | 5889mm | ||||
| B | Max. dumping height | 4201mm | ||||
| C | Max. digging depth | 3812mm | ||||
| D | Max. vertical digging depth | 3008mm | ||||
| F | Max. digging distance | 6257mm | ||||
| G | Max. digging reach at ground level | 6102mm | ||||
| H | Min swing radius of work equipment | 2585mm | ||||
| Digging Force (ISO6015) | ||||||
| Arm length | 1580mm | |||||
| A | Bucket digging force | 36.7 KN | ||||
| B | Arm digging force | 26.1 KN | ||||
Operating Weight 5820kg Heavy Duty Construction Machinery Crawler Excavator
