Product Details:
Payment & Shipping Terms:
|
| Name: | WZ30-25 Backhoe Loader | Model: | Comfort Edition |
|---|---|---|---|
| Bucket Dumping Height: | 3500mm | Bucket Dumping Distance: | 1022mm |
| Digging Depth: | 52mm | Backhoe Capacity（Width）: | 0.3m3(620mm) |
| Classification: | Heavy Duty Construction Machinery | Warranty: | 12 Months |
| High Light: | Dumping Height 3500mm Backhoe Loader,Heavy Duty Construction Backhoe Loader |
||
Bucket Dumping Height 3500mm Backhoe Loader Heavy Duty Construction Machinery
1. Backhoe loader Heavy Duty Construction Machinery product introduction
The excavation loader is a single device composed of three pieces of construction equipment. Commonly known as "busy at both ends". During construction, the operator only needs to turn the chair to change the working end. The main job of the excavators is to dig ditches to lay out pipes and underground cables, lay foundations for buildings and set up drainage systems.
2. Heavy Duty Construction Machinery WZ30-25 backhoe loader Comfort Edition product parameters
| The Performance Parameter of Backhoe Loader WZ30-25 Comfort Edition | |
| Overall Operating Weight | 6600KG |
| Transport Dimension | |
| L*W*H (mm ) | 7600×2100×3100 |
| Wheel base | 2250mm |
| Min. Ground Clearance | 300mm |
| Bucket Capacity | 1.3m3 |
| Breakout Force | 38KN |
| Loading Lifting Capacity | 2500KG |
| Bucket Dumping Height | 3500mm |
| Bucket Dumping Distance | 1022mm |
| Digging Depth | 52mm |
| Backhoe Capacity(Width) | 0.3m3(620mm) |
| Max. Digging Depth | 4082mm |
| Optional Max. Digging Depth | 5100mm(Digging arm with telescopic function) |
| Swing Angle of backhoe | 1900 |
| Max. Pulling Force | 39KN |
| Wheel tread | 1600mm |
| Wheel base | 2680mm |
| Engine | |
| Model | YUNNEI 4102 Turbo |
| Type | In Line,Direct injection,Four-Stroke,Water Cooling |
| Rated Power | 76KW |
| Rated Speed | 2400r/min |
| Displacement | 4.4L |
| Steering System | |
| Steering Angle | ±36 ° |
| Min. turning radius | 5018mm |
| Pressure of the system | 12Mpa |
| Axle | |
| Model | Wheel Hub Reducer |
| Final Reducer | Single Stage Final Reducer |
| Transmission System | |
| Torque Converter | |
| Model | YJ280 |
| Type | Single-stage Three Elements |
| Cooling Method | Oil-cooling Pressure Circulation |
| Gearbox | |
| Type | Power Transmission |
| Gears | Two Gears Ahead, Two Gears Astern |
| Max.Speed | 28Km/h |
| Optional Gears | Four Gears Ahead, Four Gears Astern |
| Max.Speed | 40Km/h |
| Tyre | |
| Model | 16/70-20 |
| Pressure of Front wheel | 0.22 Mpa |
| Pressure of Back Wheel | 0.22 Mpa |
| Brake System | |
| Service Brake | Air Over Oil Caliper Brake |
| External Type | |
| Self-regulation | |
| Self-balance | |
| Emergency Brake | Operation Power Implementing brake |
| Manual Operation Power Terminating Brake | |
| Hydraulic System | |
| Pressure of Hydraulic System | 22Mpa |
| Standard equipped | Before shovel bucket, after digging scoop, luxury interior cab, heater, fan, luxury adjustable rotating seat, adjustable dashboard, after digging shovel is hydraulic pilot before operation, the cab with push-pull window, cab can move forward (maintenance), 76 kw engine within cloud, 16/70-20 tires, 280 gearbox, the double pump, add big round edge bridge, The A-leg strap is locked. |
| The parameters or configuration are subject to change without notice. | |
FQA
Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts.
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.
Q:Delivery time :
A: Parts lead time 1-2months, machines 2-3months.
Q:Payment terms :
A: Accept payment type: T/T, L/C, Western union,Cash. 30% deposit when signed contract. Full payment paid before shipping.
Q: Quality warranty?
A: Guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.
Q: After sales service?
A: We can supply technical guide for machines running test and parts maintenance if end user needs.
