Specifically designed for the large-scale production of ultra-fine powders in non-metallic minerals, chemical raw materials, building materials, and other fields, this system offers high capacity, low loss, and long service life as its core advantages, helping you reduce costs and increase efficiency in your powder production line!

Core Working Process
The main motor drives the reducer, which in turn drives the main shaft and multi-layer turntable to rotate synchronously. Dozens of ring rollers, driven by pins, perform a composite motion of rolling and rotation within the grinding ring raceway, laying a solid foundation for efficient grinding.
Large raw materials are crushed into small particles by a hammer crusher and then transported to the storage bin by a hoist; an electromagnetic vibrating feeder evenly feeds the material to the center of the upper turntable. The material is dispersed radially by centrifugal force, falling into the grinding ring raceway, where it is powerfully compressed, rolled, and ground by the ring rollers. After three layers of progressive grinding, the small particles undergo thousands of grinding and kneading processes, ultimately transforming into ultra-fine powder.
A high-pressure centrifugal fan draws outside air into the machine, carrying the coarse powder from the three layers of grinding into the classifier. The vortex generated by the rotating turbine of the classifier causes coarse particles to fall back for regrinding, while qualified fine powder is carried by the airflow into the cyclone collector and discharged through the lower discharge valve as the finished product; the exhaust gas containing a small amount of dust is deeply purified by a pulse dust collector and then discharged through the fan and silencer to meet emission standards.


Four Core Performance Advantages
High efficiency and low consumption, leading capacity
Wear-resistant and durable, extra-long service life
Stable structure and reliable operation
Precise fineness, one-step molding

Product Parameters Of Ore Grinding Mill

Ore Grinding Mill

FAQ

Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts.
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.

Q:Delivery time:
A: Parts lead time 1-2months, machines 2-3months.

Q:Payment terms:
A: Accept payment type: T/T, L/C, Western union,Cash.
30% deposit when signed contract. Full payment paid before shipping.

Q: Quality warranty?
A: Guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.

Q: After sales service?
A: We can supply technical guide for machines running test and parts maintenance if end user needs.
