Ore Grinding Mill Ball Mill For Crushing And Grinding Of Metallic Ores Iron Copper Gold Silver
1. Ore Grinding Mill- Ball Mill Scope of Application
Our ball mills cover a full range of mining scenarios, with core application areas including:
(1)Metallic ore processing production lines: Grinding of various metallic ores including iron, copper, aluminum, gold, silver, manganese, chromium, etc.
(2)Non-metallic ore processing: Fine grinding of non-metallic ores such as limestone, talc, graphite, barite and quartz, suitable for raw material preparation in building materials, chemical, metallurgical and other industries.
(3)Large-scale production of large mining enterprises: Adaptable to different mining modes such as open-pit mines, underground mines and tailings reuse. It can be used as a single machine or matched with crushers, flotation machines, magnetic separators and other equipment to form a complete mineral processing line.
(4)Customized demand for small and medium-sized mines: Support customized equipment specifications according to ore reserves and capacity requirements to meet the personalized production needs of mining enterprises of different scales.
2. Ore Grinding Mill- Ball Mill Welcome to Inquiry and Purchase
With years of deep cultivation in the mining machinery industry, we have always adhered to the core philosophy of "Quality-oriented, Customer First". Each ball mill undergoes strict factory testing to ensure stable performance and reliable quality. Whether it is a large-scale mining project or a customized demand for small and medium-sized mining enterprises, we can provide suitable solutions and comprehensive after-sales services — including on-site installation guidance, equipment commissioning, after-sales maintenance and spare parts supply.
We sincerely invite mining enterprises, engineering contractors and mining investors to consult for quotations and field inspections. With professional technology, high-quality products and attentive service, we will help your mining project land efficiently and achieve greater benefits!
reducing the difficulty of equipment operation and maintenance for mining enterprises.
3. Ore Grinding Mill- Ball Mill Product parameters
| SPEC |
Cylinder rotation speed |
Ball loading capacity |
Feed particle size |
Discharge particle size |
Output |
Motor power |
Total weight |
| (r/min) |
(t) |
(mm) |
(mm) |
(t/h) |
(kw) |
(t) |
| Ф900×1800 |
36-38 |
1.5 |
<20 |
0.075-0.89 |
0.65-2 |
18.5 |
5.85 |
| Ф900×3000 |
36 |
2.7 |
<20 |
0.075-0.89 |
1.1-3.5 |
22 |
6.98 |
| Ф1200×2400 |
36 |
3 |
<25 |
0.075-0.6 |
1.5-4.8 |
30 |
13.6 |
| Ф1200×3000 |
36 |
3.5 |
<25 |
0.074-0.4 |
1.6-5 |
37 |
14.3 |
| Ф1200×4500 |
32.4 |
5 |
<25 |
0.074-0.4 |
1.6-5.8 |
55 |
15.6 |
| Ф1500×3000 |
29.7 |
7.5 |
<25 |
0.074-0.4 |
2-5 |
75 |
19.5 |
| Ф1500×4500 |
27 |
11 |
<25 |
0.074-0.4 |
3-6 |
110 |
22 |
| Ф1500×5700 |
28 |
12 |
<25 |
0.074-0.4 |
3.5-6 |
130 |
25.8 |
| Ф1830×3000 |
25.4 |
11 |
<25 |
0.074-0.4 |
4-10 |
130 |
34.5 |
| Ф1830×4500 |
25.4 |
15 |
<25 |
0.074-0.4 |
4.5-12 |
155 |
38 |
| Ф1830×6400 |
24.1 |
21 |
<25 |
0.074-0.4 |
6.5-15 |
210 |
43 |
| Ф1830×7000 |
24.1 |
23 |
<25 |
0.074-0.4 |
7.5-17 |
245 |
43.8 |
| Ф2100×3000 |
23.7 |
15 |
<25 |
0.074-0.4 |
6.5-36 |
155 |
45 |
| Ф2100×4500 |
23.7 |
24 |
<25 |
0.074-0.4 |
8-43 |
245 |
56 |
| Ф2100×7000 |
23.7 |
26 |
<25 |
0.074-0.4 |
12-48 |
280 |
59.5 |
| Ф2200×4500 |
21.5 |
27 |
<25 |
0.074-0.4 |
9-45 |
280 |
54.5 |
| Ф2200×6500 |
21.7 |
35 |
<25 |
0.074-0.4 |
14-26 |
380 |
61 |
| Ф2200×7000 |
21.7 |
35 |
<25 |
0.074-0.4 |
15-28 |
380 |
62.5 |
| Ф2200×7500 |
21.7 |
35 |
<25 |
0.074-0.4 |
15-30 |
380 |
64.8 |
| Ф2400×3000 |
21 |
23 |
<25 |
0.074-0.4 |
7-50 |
245 |
58 |
| Ф2400×4500 |
21 |
30 |
<25 |
0.074-0.4 |
8.5-60 |
320 |
72 |
| Ф2700×4000 |
20.7 |
40 |
<25 |
0.074-0.4 |
22-80 |
380 |
95 |
| Ф2700×4500 |
20.7 |
48 |
<25 |
0.074-0.4 |
26-90 |
480 |
102 |
| Ф3200×4500 |
18 |
65 |
<25 |
0.074-0.4 |
Determined by process conditions |
630 |
149 |
| Ф3600×4500 |
17 |
90 |
<25 |
0.074-0.4 |
Determined by process conditions |
850 |
169 |
| Ф3600×6000 |
17 |
110 |
<25 |
0.074-0.4 |
Determined by process conditions |
1250 |
198 |
| Ф3600×8500 |
18 |
131 |
<25 |
0.074-0.4 |
45.8-256 |
1800 |
260 |
| Ф4000×5000 |
16.9 |
121 |
<25 |
0.074-0.4 |
45-208 |
1500 |
230 |
| Ф4000×6000 |
16.9 |
146 |
<25 |
0.074-0.4 |
65-248 |
1600 |
242 |
| Ф4000×6700 |
16.9 |
149 |
<25 |
0.074-0.4 |
75-252 |
1800 |
249 |
| Ф4500×6400 |
15.6 |
172 |
<25 |
0.074-0.4 |
84-306 |
2000 |
280 |
| Ф5030×6400 |
14.4 |
216 |
<25 |
0.074-0.4 |
98-386 |
2500 |
320 |
| Ф5030×8300 |
14.4 |
266 |
<25 |
0.074-0.4 |
118-500 |
3300 |
403 |
| Ф5500×8500 |
13.8 |
338 |
<25 |
0.074-0.4 |
148-615 |
4500 |
525 |
