Cement Plant Equipments Concrete Flat Match Mixer for Preparing Concrete Mortar and Various Construction Applications
1. Applicable Industries of Cement Plant Equipments Concrete Flat-Match Mixer
(1) Construction Industry: Foundation, wall, and floor slab concrete pouring operations for civil buildings and industrial plants.
(2) Municipal and Road Engineering: Construction of urban roads, bridges, sidewalks, curbs, and small-scale road repair projects.
(3) Precast Component Industry: Mass production of concrete blocks, permeable bricks, curbs, precast floor slabs, etc.
(4) Mining and Tunnel Engineering: Preparation of mortar and concrete for tunnel support grouting, mine roadway spraying, etc.
(5) Agriculture and Landscape Engineering: Construction of farm facilities, greenhouse foundations, landscape walkways, and landscape concrete.
(6) Special Material Mixing: Mixing and production of special materials such as refractory materials, lightweight foamed concrete, and thermal insulation mortar.
2. Main Uses of Cement Plant Equipments Concrete Flat-Match Mixer
(1) Mixing ordinary concrete, fine aggregate concrete, dry-hard concrete, and other building mixtures.
(2) Mixing cement mortar, masonry mortar, and plastering mortar to meet the needs of various masonry and plastering operations.
(3) Preparing permeable concrete and colored pavement concrete for landscape and sponge city projects.
(4) Mixing refractory castables, thermal insulation materials, and other industrial special materials.
(5) As supporting equipment for small mixing plants, or used alone for material mixing in scattered engineering sites.
3. Core Model Parameter Table of Cement Plant Equipments Concrete Flat-Match Mixer
| Model |
Power |
Tank capacity |
Transmission case |
Tank size |
Dimensions |
Weight |
| JW350 |
4kw |
0.25m³ |
Flat gearbox |
90*40cm |
90*90*110cm |
150kg |
| JW400 |
5.5kw |
0.35m³ |
Flat gearbox |
110*40cm |
110*110*110cm |
230kg |
| JW500 |
7.5kw |
0.5m³ |
Half-bridge/Full-bridge |
130*50cm |
130*130*130cm |
480kg |
| JW750 |
11kw/7.5kw 6-pole |
0.75m³ |
Half-bridge/Full-bridge |
150*50cm |
150*150*130cm |
550kg |
| JW1000 |
15kw/11kw 6-pole |
1m³ |
Half-bridge/Full-bridge |
180*50cm |
180*180*130cm |
680kg |
| JW1500 |
18.5kw/11kw |
1.5m³ |
Full-bridge/Two-speed |
200*50cm |
200*200*130cm |
750kg |
| JW2000 |
18.5kw/15kw |
2m³ |
Full-bridge+Main reducer |
200*70cm |
200*200*160cm |
850kg |
| JW3000 |
22kw/18.5kw |
3m³ |
Full-bridge+Main reducer |
200*80cm |
220*220*160cm |
850kg |
| 3m³ |
11kw |
3m³ |
Large flat gearbox |
220*80cm |
220*220*160cm |
1000kg |
| 4m³ |
11kw |
4m³ |
Large flat gearbox |
220*80cm |
220*220*160cm |
1000kg |
| 5m³ |
11kw |
5m³ |
Large flat gearbox |
250*100cm |
250*250*190cm |
1300kg |
| 6m³ |
11kw |
6m³ |
Large flat gearbox |
280*100cm |
280*280*190cm |
1500kg |
| 8m³ |
15kw |
8m³ |
Large flat gearbox |
300*100cm |
300*280*190cm |
1800kg |
Whether you need small, portable on-site mixing equipment or large-scale, continuous industrial-grade machines, our series of flat-mouth concrete mixers provides reliable and efficient solutions to help projects progress smoothly.
