Product Details:
Payment & Shipping Terms:
|
| Name: | MP Series Vertical Shaft Concrete Mixer | Model: | MP500-2000 |
|---|---|---|---|
| Feed Capacity: | 500-2000L | Discharge Capacity: | 750-3000L |
| Ischarge Weight: | 1200-4800kg | Rated Mixing Power: | 18.5-75kw |
| Hydraulic Unloading Power: | 2.2-4kw | Hoist Power For Feeding Hopper: | 4-22kw |
| Application: | Mining Supporting Projects,Field Construction Without Power Supply | Classification: | Cement Plant Equipments |
Factory Direct Supply MP Vertical Shaft Concrete Mixer Cement Plant Equipments
1. MP Vertical Shaft Concrete Mixer Application Scope|Cement Plant Equipments
As a highly versatile concrete mixer, the MP vertical shaft model is suitable for a wide range of materials and operational environments. It handles standard commercial concrete with ease while also being capable of mixing specialized types, such as dry-hard concrete. These mixers are widely used in cement product plants, commercial concrete batching plants, road and bridge infrastructure sites, precast component factories, permeable brick production lines, and mine backfill mixing systems. They deliver stable performance across diverse scenarios—from temporary on-site mixing for construction projects to mass prefabrication in factories and underground backfill material mixing in mining operations.
2. MP Vertical Shaft Concrete Mixer Standard Technical Parameters|Cement Plant Equipments
Parameter Item | MP500 | MP750 | MP1000 | MP1500 | MP2000 |
Feed Capacity | 500L | 750L | 1000L | 1500L | 2000L |
Discharge Capacity | 750L | 1125L | 1500L | 2250L | 3000L |
Discharge Weight | 1200kg | 1800kg | 2400kg | 3600kg | 4800kg |
Rated Mixing Power | 18.5kw | 30kw | 37kw | 55kw | 75kw |
Hydraulic Unloading Power | 2.2kw | 2.2kw | 3kw | 3kw | 4kw |
Hoist Power for Feeding Hopper | 4kw | 7.5kw | 11kw | 15kw | 22kw |
Machine Size | 2230*2080*1880mm | 2580*2340*2195mm | 2890*2602*2220mm | 3230*2909*2470mm | 3625*3230*2630mm |
Machine Weight | 2400kg | 3900kg | 6200kg | 7700kg | 9500kg |
After-sales service
LUOYANG ZHONGTAI INDUSTRIES able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS
LUOYANG ZHONGTAI INDUSTRIES’s Field Service Engineers are trained specifically in the LUOYANG ZHONGTAI INDUSTRIES brand group products but are capable of undertaking the servicing of other OEM brands. Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time. LUOYANG ZHONGTAI INDUSTRIES also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.
Factory Direct Supply MP Vertical Shaft Concrete Mixer Cement Plant Equipments![]()
Factory Direct Supply MP Vertical Shaft Concrete Mixer Cement Plant Equipments![]()
Factory Direct Supply MP Vertical Shaft Concrete Mixer Cement Plant Equipments
