Clinker Double Roller Dia 1630MM 2350t/H Stone Crusher Machine



Supply Ability:50 Set/Sets per Month

Production capacity:80-4000 t/h

Port:Qingdao,Tianjin, Shanghai or others

Feature:simple structure, takes up smaller space





Model	Roller diameter mm	Capacity t/h	Broken materials	feeding size mm	Discharging size mm
2PGC-1630	Φ1630	2350	Raw coal	0-1800	0-300
2PGC-1370A	Φ1370	2000	stone,coal	0-1500	0-300
2PGC-1370B	Φ1370	2000	limestone	0-1500	0-300
2PGC-1270	Φ1270	1200	Raw coal	0-1200	0-300
2PGC-980	Φ980	500	coal	0-1000	0-200
2PGC-600	Φ600	100	limestone	0-300	0-100
2PGC-550	Φ550	80	coal	0-300	0-50
2PGCF-820	Φ820	2000	Raw coal	0-330	0-50

























The values in this table represent a typical sizer and are dependent on the tonnage rate and tooth configuration required.

Product advantage:

1. Gear roller shaft, gear crown and grid plate adopt inner passage water-cooling system with outstanding cooling effect (the gear crown temperature is 60°C after being off for 10 min ) to increase the life time of the gear roller and the grid plate.
2. The retarder adopts fully sealed gearbox structure with low operation noise and no oil leakage.
3. Fully sealed rolling bearing to provide easy maintenance and lower maintenance cost.
4. The screw tooth roller to increase the breaker life time for 1-2 times.
5. The tooth plate is fixed on the hub for easy replacement and save the time and energy.
6. The tooth plate is made of alloy steel and the wearing-resistant layer is formed on the surface to guarantee 40000 h life time.
7. Safe sleeve shaft is provided at the tooth roller drive end. The breaker can stop in case of abnormality, such as overload to protect the equipment.



1. Coarse breaking for the metallurgy sinter mine in the working temperature of lower than 900°C in the steel manufacturer.
2. Coarse breaking and intermediate breaking of hard brittle materials with breaking pressure lower than 20kN/cm2 in the concentration plant, stone plant and power generation plant.

Principle structure of toothed single roll crusher

Toothed single roll crusher is consisted of rotary roller with large tooth and adjustable crushing plate. The material is smashed, pressed or rumpled in the single-tooth roll breaker. When the materials enter into the breaking cavity from top of the hopper, the material is brought into the breaking cavity between the tooth roller and crushing plate by the rotary roller for breaking. The crushed materials will be discharged by the self-gravity from the discharging port. The clearance between the crushing plate and the tooth roller can be adjusted to control the particle size of the crushed materials.







CITIC Heavy Industries is your business partner in the After Market.

CITICIC  able to provide:

1.    ENGINEERED SPARES -  DESIGN AND MANUFACTURING

2.    LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES

3.    HUGE MACHINE SHOP CAPABILITIES

4.    TRAINING PROGRAMMES

5.    PREVENTATIVE MAINTENANCE PROGRAMS

6.    PREVETATIVE MAINTENANCE SERVICES

7.    COMPREHENSIVE MAINTENANCE PROGRAMS

 CITIC’s Field Service Engineers are trained specifically in the CITIC brand group products but are capable of undertaking the servicing of other OEM brands.

 Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time.

 CITICIC also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.


Quality Control

Physical & Chemical Identification Center

CITICIC owns a professional testing and metrology institute which provides advanced testing methods such as nondestructive testing, industrial chemical analysis, metallographic testing and analysis, mechanical testing, sample preparation, meter/length measurement, weighing apparatus verification, and weighman inspection. Our metrology institute has taken a leading role in China.

CITICIC owns nearly two hundred types of advanced testing equipment, nine different measurement standards and nearly twenty types of world-class testing equipment which have been imported from international locations such as Germany, Japan, USA, UK and Belgium.
