Product Details:
Payment & Shipping Terms:
|
Product Name: | Active Lime Calcining Equipment | Keywords: | Lime Rotary Kiln |
---|---|---|---|
Key Selling Points: | Energy Saving | Material: | Steel |
Quality: | High Standard | As Details: | Cement Plant, Steel Mill, Chemical Plant & Incinerator |
High Light: | 1005m3 Lime Rotary Kiln,4.8×68 Lime Rotary Kiln,1005m3 rotary calcination kiln |
High productivity Active Lime Calcining Equipment Lime Rotary Kiln
Description of Lime Rotary Kiln (Active Lime Calcining Equipment):
Active lime can be widely used in a wide range of industries, such as steel, alumina, magnesium, calcium carbide, papermaking field, etc. As an important auxiliary material, active lime can not only help to improve the quality and output of steel, but also reduce the consumption and costs as well as ensure stable operation of steel industry. Considering the potential economic benefits of active lime for various fields, CITIC HMC Co., Ltd has developed the 1000t/d lime rotary kiln for customers worldwide. And now this machine has been well received by clients from Vietnam, Russia, Central Africa, and more.
Advantages of Lime Rotary Kiln (Active Lime Calcining Equipment):
1. High productivity makes it possible for our lime rotary kiln to be used in large active lime production line.
2. Open-type calcining rotary kiln has a simple structure, and can discharge sulfurous gases timely, which makes it quite suitable for steelmaking.
3. It is capable of calcining 10 to 50mm fine limestone directly.
4. Vertical preheater has been equipped at the end of the kiln to make full use of high-temperature gases generated during calcining. It can preheat limestone to the decomposition conditions. In this way, it helps not only to increase the output, but also to decrease the heat consumption.
5. The equipped vertical cooler at the head of the kiln can help cool the high-temperature limestone, as well as make it convenient to convey and store. Besides, it can effectively increase the temperature inside the kiln, thus reducing the fuel consumption.
6. Waste gases, discharged from the vertical preheater, have a temperature ranging from 280℃ to 350℃, and their dust content is about 20g/Nm3. So it is easy to deal with these gases according to the requirements of environmental protection.
7. With stable performance, our active lime calcining equipment is also suitable for mine exploitation.
K-K Active lime rotary kiln Parametes
Capacity(t/d) | 150 | 200 | 250 | 300 | 350 | 400 | 500 | 600 | 750 | 800 | 1000 | |||||
product | Active lime Light burned dolomite |
Active lime Light burned dolomite |
Active lime Light burned dolomite |
Active lime Light burned dolomite |
Active lime | Active lime | Active lime | Active lime | Active lime | Active lime | Active lime | |||||
preheater | Circular vertical preheater | Circular vertical preheater | Circular vertical preheater | Circular vertical preheater | Circular vertical preheater | Circular vertical preheater | Circular vertical preheater | Circular vertical preheater | Multilateral vertical preheater | Multilateral vertical preheater | Multilateral vertical preheater | |||||
Rotary
Kiln |
specifications(m) | Φ2.5×40 | Φ2.8×42 | Φ3×46 | Φ3.2×50 | Φ3.5×54 | Φ3.6×56 | Φ3.8×58 | Φ4×60/ Φ4.2×50 | Φ4.3×58 | Φ4.3×64 | Φ4.8×68 | ||||
Effective volume(m3) | 142 | 190 | 235 | 292 | 390 | 430 | 505 | 575/548 | 670 | 738 | 1005 | |||||
Combustion temperature | 1350/1250 | 1350/1250 | 1350/1250 | 1350/1250 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 | |||||
cooler | Circular vertical cooler | Circular vertical cooler | Circular vertical cooler | Circular vertical cooler | Circular vertical cooler | square vertical cooler | square vertical cooler | square vertical cooler | square vertical cooler | square vertical cooler | square vertical cooler | |||||
fuel | gas; Pulverized coal |
gas; Pulverized coal |
gas; Pulverized coal |
gas; Pulverized coal |
gas; Pulverized coal |
gas; Pulverized coal |
gas; Pulverized coal |
gas; Pulverized coal |
gas; Pulverized coal |
gas; Pulverized coal |
gas; Pulverized coal |
|||||
heat rate (KJ/KgCaO) |
5300/5000 | 5300/5000 | 5300/5000 | 5300/5000 | 5225 | 5225 | 5100 | 5100 | 4810 | 4810 | 4810 |
|
