950-13000 Kg Ore Dressing Equipment coarse coal centrifuge

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

950-13000 Kg Ore Dressing Equipment coarse coal centrifuge

950-13000 Kg Ore Dressing Equipment coarse coal centrifuge
950-13000 Kg Ore Dressing Equipment coarse coal centrifuge 950-13000 Kg Ore Dressing Equipment coarse coal centrifuge 950-13000 Kg Ore Dressing Equipment coarse coal centrifuge 950-13000 Kg Ore Dressing Equipment coarse coal centrifuge

Large Image :  950-13000 Kg Ore Dressing Equipment coarse coal centrifuge

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: According to customer demand
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month
Detailed Product Description
Name: Centrifuge Diameter(mm): 250-800
Lenght(mm): 900-3200 Max Speed: 1800-5000
L/D Ratio: 3-4 G-force: 1306-2964
Capacity(m3/h): 0.5-120 Main Motor Power(Kw): 7.5-150
Weight(kg): 950-13000 Dimension(mm): Different Model
High Light:

13000Kg Ore Dressing Equipment

,

13000Kg Coarse Coal Centrifuge

,

950kg Coarse Coal Centrifuge

950-13000 kg High-performance Environmental protection centrifuge



Coal chemical industry refers to the process of converting coal into gas, liquid, and solid fuels and chemicals through chemical processing. It mainly includes coal gasification, liquefaction, dry distillation, tar processing, and calcium carbide acetylene processing. Coal chemical processing. The chemical structure of organic matters in coal takes the condensed nucleus of aromatic (mostly) as a unit core, which is of bridged linkage and has a macromolecular structure with various functional groups. Through thermal and catalytic processing, coal can be converted into various kinds of fuels and chemical products.

The heavy liquid phase separated by the centrifuge can adopt two different liquid discharging modes.

1.High-performance sealing structure can effectively reduce the overflow of irritating gas, improve the air quality at the operation site, and reduce environmental pollution;
2.High-performance sealing material can effectively avoid the swelling failure of ordinary rubber parts;
3.The coke button in the coal tar is an important factor affecting the stability and service life of the centrifuge due to abrasion.

950-13000 Kg Ore Dressing Equipment coarse coal centrifuge 0



Model Diameter(mm) Lenght(mm) Max speed L/D ratio G-force Capacity(m3/h) Main motor power(Kw) Weight(kg) Dimension(mm)
LW250*1000 250 1000 5000 4 2722 0.5-5 7.5 950 2120*1250*680
LW300*900 300 900 4200 3 2964 1-6 11 1160 2150*1300*900
LW300*1200 300 1200 4000 4 2784 2-6 11 1350 2450*1300*900
LW355*1160 355 1160 3600 3.3 2576 2-8 15 1400 2470*1350*830
LW355*1460 355 1460 3600 4 2576 2-10 15 1800 2750*1350*830
LW400*1200 400 1200 3200 3 2294 3-12 18.5 1800 2730*1600*1080
LW400*1600 400 1600 3000 4 2016 3-15 22 2000 3130*1600*1080
LW450*1800 450 1800 2800 4 1976 4-25 37 2500 3320*1700*1130
LW500*2000 500 2000 2800 4 1750 5-35 45 4000 3520*1800*1170
LW530*1855 530 1855 2600 3.5 2006 5-38 55 4680 3885*1350*1600
LW530*2120 530 2120 2400 4 1709 5-40 55 4800 4150*1350*1600
LW550*2000 550 2200 2800 4 2414 6-40 55 5700 4570*1380*1600
LW650*1950 650 1950 2200 3 1761 6-45 75 5000 4840*1510*1720
LW650*2600 650 2600 2000 4 1456 6-65 90 6000 5490-1510*1720
LW720*2160 720 2160 2000 3 1612 7-80 120 6000 5200*1600*1800
LW720*2880 720 2880 2000 4 1306 7-90 120 8000 3100*1600*1800
LW800*2400 800 2400 1800 3 1451 20-100 150 12000 5820*2000*1300
LW800*3200 800 3200 1800 4 1451 20-120 150 13000 7100*2000*1300
