Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process

Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process
Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process

Large Image :  Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: According to customer demand
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month
Detailed Product Description
Product Name: Vibration Screen Application: Product Classification
Layer: 1-3 Max Particle Size: <400
Sieve Size(mm): 1--25 Amplitude: 2--7
Capacity: 10-500tph Angle(°): 15--25
Power(kw): 2.2-30 Dimension: Different Model
High Light:

500tph Circular Vibrating Screen

,

Stone Ore Circular Vibrating Screen

,

500tph circular motion vibrating screen

multi-layer high-efficiency new vibrating screen for Stone Ore Mining Process

Vibration screen Introduction:
The circular vibrating screen causes the motion trajectory to approximate a circle, so it is simply referred to as a circular vibrating screen. The circular vibrating screen is a multi-layer, high-efficiency new vibrating screen.
The circular vibrating screen adopts the simplified eccentric shaft exciter and the eccentric block to adjust the amplitude. The material sieve has a long line and many screening specifications. It is widely used in product classification of mining, building materials, transportation, energy, chemical and other industries.

Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process 0
Performance characteristics of our vibrating screen :
① The material sieve line length is long, and the screening specifications are many.
② The block eccentricity is used as the exciting force, and the exciting force is strong.
③ The sieve beam and the screen box are connected by high-strength bolts without welding.



Model(mm) layer max particle size sieve size(mm) amplitude capacity angle(°) motor power(kw) dimension
model L*W*H
SZZ2600*1200 1 40 1--25   10--20 15--25 Y112L1-4 2.2 1370*890*330
SZZ2600*1200 2 40 1--25 6 10--20 15--25 Y112L1-4 2.2 1370*890*430
SZZ900*1800 1 40 1--25 6 20--25 15--25 Y112L1-4 2.2 2150*1358*575
SZZ2900*1800 2 40 1--25 6 20--30 15--25 Y112L2-4 3 2489*1358*770
SZZ1250*2500 1 100 5--40 2--7 150 15--20 Y1321S1-4 5.5 2762*1714*680
SZZ21250*2500 2 150 5--40 2--7 150 15--20 Y1321S1-4 5.5 2762*1714*740
SZZ1500*300 1 100 1--40 8 220 15--25 Y132M1-4 7.5 3320*1449*787
2YA1848 2 <400 5--80 8 50--260 20 Y180M-4 18.5 5120*2950*3060
3YA1860 3 <400 5--80 8 50--350 20 Y180L-4 22 6260*2990*3960
3YA2160 3 <400 5--100 6--8 100--500 20 Y200L-4 30 6270*3470*4100



Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process 1Multi layer 500tph Circular Vibrating Screen For Stone Ore Mining Process 2
