Product Details:
Payment & Shipping Terms:
|
| Mobile Crusher: | Mobile Jaw Crusher/Mobile Impact Crusher | Motor Type: | AC Motor |
|---|---|---|---|
| Capacity(t/h): | 20-700 Tph | Warranty: | 12 Months |
| Feature: | Reduce Material, Flexibility, Used Independently | Mobile Jaw Crusher: | 90-650 Tph |
| Supply Ability: | 50 Set/Sets Per Month | Brand: | CITIC |
| Feeding Size: | >2500mm | Port: | Qingdao,Shanghai,Tianjin |
| High Light: | 700tph Stone Crusher Machine Plant,200tph Stone Crusher Machine Plant,700tph Basalt Aggregate Production Line |
||
Mining Equipment Stone Crushing Plant Basalt Aggregate Production Line Stone Crusher Crushing Machine
Mobile crusher
| Technical Data//Model | LYCJ69 | LYCJ750 | LYCJ912 | LYCJ860 | LYCJ1100 | |
| Transportation size(mm) | 11900×2550×3650 | 13500×2550×4300 | 15200×2950×4450 | 14600×2750×4350 | 15200×2800×4900 | |
| Weight(t) | 35 | 52 | 80 | 59 | 85 | |
| Tire Configuration | Dualaxial | Triaxial | Triaxial | Triaxial | Triaxial | |
| Jaw Crusher | PE600×900 | PE750×1060 | PE900×1200 | PEW860 | PEW1100 | |
| The Maximum Feeding Size(mm) | 480 | 630 | 750 | 730 | 940 | |
| Discharge Opening Size(mm) | 65~160 | 80~140 | 100~200 | 75~225 | 150~275 | |
| Capacity(t/h) | 90~180 | 110~320 | 220~450 | 150~500 | 300~650 | |
| Vibrating Feeder | GZD960×3800 | GZD1100×4200 | GZD1300×4900 | GZD1300×4900 | GZD1300×4900 | |
| Main Belt Conveyor | B800×8.5M | B1000×9M | B1200×9.5M | B1200×9.5M | B1200×9.5M | |
| Side Belt Conveyor (optional) | B450×3M | B500×3.5M | B650×4M | B650×4M | B650×4M | |
| Electric control | standard | control box + control panel | control box + control panel | control box + control panel | control box + control panel | control box + control panel |
| optional | Control box + LCD | Control box + LCD | Control box + LCD | Control box + LCD | Control box + LCD | |
| Hydraulic leg | standard | 4 | 4 | 4 | 4 | 4 |
| optional | 2 | 2 | 2 | 2 | 2 | |
| Hydraulic cylinder | standard | 4 | 4 | 4 | 4 | 4 |
| optional | 5 | 5 | 5 | 5 | 5 | |
| Genset (optional)(Kw) | 180 | 250 | 250 | 270 | 380 | |
| Iron Separator (optional) (Kw) | RCYD(C)-8 | RCYD(C)-10 | RCYD(C)-12 | RCYD(C)-12 | RCYD(C)-12 | |
Note:Any change of technical data shall not be advised additionally.
| Technical Data//Model | LCI1214Ⅱ | LCI315Ⅱ | LCI318Ⅱ | |
| Transportation size(mm) | 11900×2650×3850 | 13500×2780×4150 | 15200×2950×4300 | |
| Weight(t) | 41 | 52 | 61 | |
| Tire Configuration | Dualaxial | Triaxial | Triaxial | |
| Impact Crusher | PFW-1214Ⅱ | PFW-1315Ⅱ | PFW-1318Ⅱ | |
| The Maximum Feeding Size(mm) | 500 | 600 | 700 | |
| Capacity(t/h) | 130~200 | 180~320 | 240~400 | |
| Vibrating Feeder | GZD960×3800 | GZD1100×4200 | GZD1300×4900 | |
| Main Belt Conveyor | B800×8.5M | B1000×9M | B1200×9.5M | |
| Side Belt Conveyor (optional) | B450×3M | B500×3.5M | B650×4M | |
| Electric control | standard | control box + control panel | control box + control panel | control box + control panel |
| optional | Control box + LCD | Control box + LCD | Control box + LCD | |
| Hydraulic leg | standard | 4 | 4 | 4 |
| optional | 2 | 2 | 2 | |
| Hydraulic cyclinder | standard | 4 | 4 | 4 |
| optional | 5 | 5 | 5 | |
| Genset (optional) (Kw) | 270 | 380 | 440 | |
| Iron Separator (optional)(Kw) | RCYD(C)-8 | RCYD(C)-10 | RCYD(C)-12 | |
Aftersales service
LUOYANG ZHONGTAI INDUSTRIES able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS
LUOYANG ZHONGTAI INDUSTRIES’s Field Service Engineers are trained specifically in the LUOYANG ZHONGTAI INDUSTRIES brand group products but are capable of undertaking the servicing of other OEM brands.
Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time.
LUOYANG ZHONGTAI INDUSTRIES also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.
Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.
Q:Delivery time
A: parts lead time 1-2months, machines 2-3months.
Q:Payment terms
A: Accept payment type: T/T, L/C, Western union,Cash.
30% deposit when signed contract. Full payment paid before shipping
Q: Quality warranty?
A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.
Q: After sales service?
A: we can supply technical guide for machines running test and parts maintenance if end user needs.
