1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment

1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment
1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment 1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment 1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment

Large Image :  1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: According to customer demand
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month
Detailed Product Description
Quality: ISO/CE Product Name: Jaw Crusher
Feed Openning Size(mm): 1200x1500 Max Feeding Size(mm): 1020
Discharge Range(mm): 10-40 Capacity(t/h): 400-800
Power: 220 Weight: 100
Usage: Mining, Building Materials, Chemical Industry, Metallurgy And So On Advantage: High Efficiency
High Light:

800Tph Jaw Crusher Machine

,

1Tph Jaw Crusher Machine

,

800Tph universal jaw crusher

1-800 tph output High efficiency jaw crusher crushing equipment

High efficiency jaw crusher

The Jaw Crusher is widely used in mining, building materials, chemical industry, metallurgy and so on. The Jaw Crusher is suitable for primary and secondary crushing all kinds of minerals and rocks with compressive strength less than 320 MPa.

1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment 0

Working principle



The motor transmits through belt, drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft. The angle between toggle plate and moving jaw plate increases when mobile jaw moving. So the mobile jaw moves towards the fixed jaw. The stuff will be crushed in this process. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw moves leaves fixed jaw by pulling rod and spring, the final crushed stuff will be discharged from the outlet.

Product

1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment 1

Specifications





Model Feed openning size(mm) Max feeding size(mm) Discharge range(mm) Capacity(t/h) Power Weight
PE150x250 150x250 125 10-40 1-3 5.5 0.7
PE250x400 250x400 210 20-60 5-120 15 2.8
PE400x600 400x600 340 40-100 30-50 30 7
PE500x750 500x750 425 50-180 35-80 55 12
PE600x900 600x900 500 50-180 80-150 75 17
PE750x1060 750x1060 630 80-140 110-320 90 31
PE900x1200 900x1200 750 95-165 220-350 160 52
PE1200x1500 1200x1500 1020 150-350 400-800 220 100
PE150x750 150x750 120 18-48 10-25 15 3.8
PE250x750 250x750 210 15-60 15-35 30 6.5
PE250x1000 250x1000 210 15-60 16-52 37 7
PE250x1200 250x1200 210 15-60 20-60 45 9.7



1-800 Tph Output High Efficiency Jaw Crusher Machine Crushing Equipment 2
