Product Details:
Payment & Shipping Terms:
|
| Name: | Impact Crusher | Condition: | New |
|---|---|---|---|
| Motor Type: | AC Motor | Capacity(t/h): | 30-550 |
| Weight: | 56t | Max Feeding Size: | 770mm |
| Warranty: | 12 Months | Port: | Qingdao, Shanghai |
| High Light: | 550TPH Riverstone Rock Crushing Machine,770mm Quarry Rock Crushing Machine,550TPH stone impact crusher |
||
Quarry limestone gravel concrete riverstone clay rock crushing machine, vertical shaft fine stone impact crusher
Impact Crusher can crush the large, medium and small size materials (granite, limestone, concrete ,etc.)With max feed size less than 500mm and compression strength less than 350Mpa. Presently, by practices, its comprehensive function is superior to the cone crusher and the hammer crusher.
Vertical impact crusher
|
model |
feeding size(mm) |
power(kw) |
Impeller speed (r/min) |
processing capacity(t/h) |
Dimension(mm) |
Weight (including motor)(t) |
|
PCL-750 |
45 |
2×55 |
1700-2000 |
50-90 |
3300×1800×2440 |
7.3 |
|
PCL-800 |
55 |
2×75 |
1400-1620 |
80-150 |
3750×2120×2090 |
12.1 |
|
PCL-900 |
65 |
2×90 |
1300-1550 |
100-180 |
3750×2300×2660 |
13.6 |
|
PCL-1050 |
80 |
2×(132-160) |
1200-1400 |
180-350 |
4480×2450×3906 |
16.9 |
|
PCL-1250 |
100 |
2×(220-250) |
1000-1100 |
310-580 |
4563×2650×3716 |
22 |
|
PCL-1350 |
110 |
2×(250-280) |
900-1000 |
400-650 |
5340×2940×3650 |
26 |
Vertical impact crusher equipment characteristics:
1, the unique design of the rotor and cavity, a large amount of processing and a high rate of sand, product grain type, needle flake content is low, pushing density
2, the material and material from the collision and self lining mechanism to reduce the contact between the material and the metal, to extend the life of the wearing parts, reducing the iron contamination of finished products
3, the unique wear-resistant structure and material to extend the service life, reduce operating costs
4, special rotation structure, so that the equipment running at high speed, can be equipped with automatic control system, electric hoist, hydraulic hoist device, vibration sensor device, the cumulative boot timing device to ensure the safe operation of equipment
5, the clever design of the internal air circulation to eliminate the dust dispersion
6, the structure is simple, easy to operate and maintain, is a new technology, new technology fully reflected
Aftersales service
LUOYANG ZHONGTAI INDUSTRIES able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS
LUOYANG ZHONGTAI INDUSTRIES’s Field Service Engineers are trained specifically in the LUOYANG ZHONGTAI INDUSTRIES brand group products but are capable of undertaking the servicing of other OEM brands.
Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time.
LUOYANG ZHONGTAI INDUSTRIES also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.
Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.
Q:Delivery time
A: parts lead time 1-2months, machines 2-3months.
Q:Payment terms
A: Accept payment type: T/T, L/C, Western union,Cash.
30% deposit when signed contract. Full payment paid before shipping
Q: Quality warranty?
A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.
Q: After sales service?
A: we can supply technical guide for machines running test and parts maintenance if end user needs.
