60-90 t/h Sand Making Equipment VSI Sand Making Machine

60-90 t/h Sand Making Equipment VSI Sand Making Machine
60-90 t/h Sand Making Equipment VSI Sand Making Machine 60-90 t/h Sand Making Equipment VSI Sand Making Machine 60-90 t/h Sand Making Equipment VSI Sand Making Machine 60-90 t/h Sand Making Equipment VSI Sand Making Machine 60-90 t/h Sand Making Equipment VSI Sand Making Machine

Large Image :  60-90 t/h Sand Making Equipment VSI Sand Making Machine

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: According to customer demand
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard shipping packaging
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month
Detailed Product Description
Features: Low Energy Consumption, Large Capacity And Crushing Ratio Product Name: VSI Sand Making Machine
Capacity (t/h): 60-90 Feeding Size (mm): ≤35
Rotation Speed(r/min): 1700-1890 Double Motor Power(kw): 110-150
Weight(t): 7.8 Voltage: 380 V
Item: Sand Making Machine Usage: Fine Crushing And Coarse Grinding
High Light:

90T/H Sand Making Equipment

,

60T/H Sand Making Equipment

,

90T/H VSI Sand Making Machine

high performance sand making equipment VSI sand making machine



Product Description
VSI sand making machine is high performance sand making equipment widely used for fine crushing and coarse grinding of ores, cement, refractory material, grinding material, glass raw material, building aggregates, artificial sand and all kinds of metallurgical slag.
VSI7611 sand making machine Max. feeding size id 35 mm, capacity is 60-180 tph, motor powder is 110-150 kw. It is especially suitable for medium hardness materials, high hardness materials and corrosion resistance materials, such as cobble, granite, basalt, iron ore, limestone, calcite, quartzite, etc.

60-90 t/h Sand Making Equipment VSI Sand Making Machine 0

Working Principle
1. Central feeding: Raw materials fall down into the feeding hopper of the VSI sand making machine, then enters the impeller through central entrance inlet, thus the material being accelerated by the high-speed impeller and being thrown out at the speed of 60-75 m/s. It is crushed when hitting the impact plate, and the end products comes out from the discharging outlet.
2. Ring feeding: Raw materials fall down into the feeding hopper, and the materials are divided into two parts by a special plate. Some materials enter the sand making machine’s impeller through the center of the plate and the other part of materials falls down from outside of the plate. The materials thrown out earlier crush the materials down from outside, thus the materials crushed and re-crushed.

VSI Sand Making Machine Features
1. Unique structure and stable operation.
2. Low energy consumption, large capacity and crushing ratio.
3. Perfect cubic product size and high bulk density.
4. Less spare parts, long service life and easy to change.

Model
VSI7611
VSI8518
VSI9526
Capacity
(t/h)
Cascade and center feeding
120-180
200-260
300-380
Center feeding
60-90
100-130
150-190
Feeding size
(mm)
Soft material
≤35
≤40
≤45
Hard material
≤30
≤35
≤40
Rotation speed(r/min)
1700-1890
1520-1690
1360-1510
Double motor power(kw)
110-150
180-220
264-320
Weight(t)
7.8
10.3
16
Voltage
380 v 50Hz



60-90 t/h Sand Making Equipment VSI Sand Making Machine 160-90 t/h Sand Making Equipment VSI Sand Making Machine 2
