10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
Thanks for your kindly hospitality. Your company is very professional , we will have nice cooperation in the near future.

—— James

Good company with nice service and high quality and high reputation. One of our reliable supplier , goods are delivered in time and nice package.

—— Sammel

Through very good communication all problems solved, satisfied with my purchase.

—— Alexandra

Recommedation is good. Reception is professional. Demo training is also very great. Wish more online training after getting the machine.

—— George

Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Abby

I'm Online Chat Now

10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill

10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill
10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill 10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill 10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill

Large Image :  10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill

Product Details:
Place of Origin: Henan, China
Brand Name: CITIC HIC
Certification: ISO CE
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set/Sets
Price: $2,000.00 - $5,000.00 / Set
Packaging Details: Simple package for hammer crusher
Payment Terms: T/T, L/C
Supply Ability: 1000 Set/Sets per Year
Detailed Product Description
Product Name: Hammer Crusher Condition: New
Motor Type: AC Motor Capacity(t/h): 3-260 Tph
Dimension(L*W*H): 5800x3780x2700 Mm Weight: 0.9-35.2
Warranty: 12 Months Rotor Length (mm): 400-1600
Material Strength: Less Than 150Mpa Max. Feeding Side Length(mm): 80-350
Discharging Particle Size(mm): ≤25 Color: Customizable
Motor: Chinese Famous Brand Port: QingDao,ShangHai,TianJin
High Light:

25 Tph Hammer Mill Rock Crusher

,

10Tph Hammer Mill Rock Crusher

,

10Tph Mobile Mini Hammer Crusher

10-25tph Hot Sale Hammer Mill Crusher Series Mobile Mini Hammer Crusher Mill For Sale



Product Description

Hammer crusher

This machine is suitable for crushing medium-hardness materials such as limestone, slag, coke, coal and so on in cement, chemical, electric power, metallurgy and other industrial departments. It has the advantages of simple structure, large crushing ratio and high production efficiency, which can break both dry and wet forms., Hammer Crusher can adjust grate strip gap according to user's requirement,Change the size of the material, This can meet the different needs of different users.



 Specification of hammer crusher

Type Rotor diameter
(mm)
Rotor length
(mm)
Max. Feeding side length(mm) Discharging particle size(mm) Production capacity
(t/h)
Power of motor     (KW) Weight
(t)
Outline dimension(mm) Length× width× Height
PC-0404 φ400   400 80 ≤15 3--5 7.5 0.9 1518 1010 630
PC-0604 φ600 400 100 ≤15 6—10 18.5 1.5 1755 1210 785
PC-0606 φ600 600 100 ≤15 10—18 37—45 2.5 2115 1210 785
PC-0808 φ800 800 160 ≤15 18—30 55—75 3.5 2855 1360 1040
PC-1010 φ1000 1000 200 ≤20 35—55 110-132 7.6 3514 1850 1400
PC-1012 φ1000 1200

200

≤20 45—65 132 8.5 4055 1850 1400
PC-1212 φ1250 1200 200 ≤20 70--110 160-185 14.1

4475

1920

1910

PC-1414 φ1430 1400 250 ≤25 110--160

280

25.6

5467 2465 2260
PC-1616 φ1600 1600 350 ≤25 180--260 500 35.2 5800 3780 2700

 Note:
1. This equipment can control the Max. Value of the discharging particle size with screen plate.
2. When liquid water content is larger than 8%, it is easy to block screen hole to influence the capacity.

10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill 0

10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill 1

10-25 tph Hammer Mill rock Crusher Mobile Mini Hammer Crusher Mill 2
Main features
1,Big feed input, high crushing cavity, Suitable for high hardness of material, large block degree, less stone powder
2,The material is suspended and the power consumption is small.
3.Novel hammerhead, Great impact
4.Hammer shaft installation adjustable, long life hammerheadr.
5,Grid size adjustable, product granularity controllable, particle shape is good.
6,Chassis can be flipped, overhaul more convenient
7,Square shank bolts, shock resistance, abrasion resistance
8,Compact structure, strong machine rigidity.
9,Assembly structure, easy to carry and install.
10,This machine set impact, counterattack, impact crushing function in a, high production efficiency, mechanical wear small, comprehensive benefit is remarkable.
Our Services

Aftersales service

LUOYANG ZHONGTAI INDUSTRIES able to provide:

1. ENGINEERED SPARES - DESIGN AND MANUFACTURING

2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES

3. HUGE MACHINE SHOP CAPABILITIES

4. TRAINING PROGRAMMES

5. PREVENTATIVE MAINTENANCE PROGRAMS

6. PREVETATIVE MAINTENANCE SERVICES

7. COMPREHENSIVE MAINTENANCE PROGRAMS

LUOYANG ZHONGTAI INDUSTRIES’s Field Service Engineers are trained specifically in the LUOYANG ZHONGTAI INDUSTRIES brand group products but are capable of undertaking the servicing of other OEM brands.

Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time.

LUOYANG ZHONGTAI INDUSTRIES also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.

FAQ

Q: Why we believe in luoyang zhongtai industries co., ltd:

A: 1. More than 30 years experience.

     2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged      parts

     3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.



Q:Delivery time

A: parts lead time 1-2months, machines 2-3months.



Q:Payment terms

A: Accept payment type: T/T, L/C, Western union,Cash.

30% deposit when signed contract. Full payment paid before shipping



Q: Quality warranty?

A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.



Q: After sales service?

A: we can supply technical guide for machines running test and parts maintenance if end user needs.
