High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln

High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln
High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln

Large Image :  High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: regular packing
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 300 sets per month
Detailed Product Description
Product Name: Bauxite Rotary Kiln Type: Rotary Drying Equipment
Application: Chemicals Processing Certification: ISO/CE
Productivity (t/d): 72-5000 Power (kw): 30-630
Speed Ratio: 28-134.9 Weight (t): 66-841
Warranty: 1 Year Key Selling Points: Energy Saving
High Light:

5000 TPD Cement Rotary Kiln

,

72TPD Cement Rotary Kiln

,

5000 TPD Bauxite Rotary Kiln

Description of Bauxite Rotary Kiln:
Our bauxite rotary kiln can be used in a wide range of fields, such as dolomite, kaolin, bauxite, refractories, cement, limestone, vanadium minerals, activated carbon, coke, mineral powder, alumina, magnesium oxide, zinc oxide, special cement, etc.


It has features of energy saving, high productivity, decarburization whitening, simple structure, long lifespan, easy maintenance, etc.
High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln 0
ZTIC Bauxite Rotary Kiln technical characteristics:


Kiln body is made of high quality composed of carbon steel or alloy steel plate and automatic welding;
Tyre,Support Roller,Open gear adopts alloy cast steel;
Sliding bearing with large gap not scraping tile bearing;
Transmission device adopts hard tooth surface reducer, flexible diaphragm coupling, dc motor;
Adopts hydraulic gear wheel;
Preheater scales were used respectively to veiw of kiln head, and cylinder pressure tight seal;
A slow drive device

High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln 1

As a professional manufacturer and supplier of bauxite rotary kiln in China,ZTIC HMC Co., Ltd can also provide you with various other machines, such as titanium dioxide rotary kiln, vertical preheater, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. Most of our products have passed the certification of ISO9000 and CE, and they have been quite popular among customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Iran, Japan, South Korea, Bengal, Pakistan, Turkey, Burma, Vietnam, South Africa, Columbia, Bolivia, etc. If you need bauxite rotary kiln, please don't hesitate to contact us.

High Productivity 72-5000 TPD Cement Rotary Kiln Bauxite Rotary Kiln 2

Parameters of Bauxite Rotary Kiln:



Specification (m) Productivity (t/d) Main motor
Model Power (kw)
φ18×26 72 JZT2-72-4 30
φ1.9/1.6×39 72 JZT2-72-4 30
φ1.9×36 84 YCT315-4A 37
φ2.2×45 98.4 JZT82-6 55
φ2.5×40 160 Z2--92 40
φ2.5×45 170 JTZ82-4 45
φ2.5×50 180 ZT3-72-4 30
φ2.5×60 168 YCT355-4B 75
φ3×48 360-480 YCT355-4B 75
φ3.1/2.5×78 216-240 Z4-225-31 75
φ3×48 700 ZSN4-280-21B 110
φ3×100.94 450 ZSN4-280-21B 90
φ3.2×50 1000 ZSN4-280-21B 160
φ3.2×52 600 ZSN4-280-21B 125
φ3.3×52 1000 ZSN4-280-11B 125
φ3.5×52.5 1400 Z2-112 180
φ3.5×54 1500 ZSN4-3156-092 220
φ3.6×70 490 ZSN4-280-11B 125
φ3.95×56 2000 Z4-280-32BTH 250
Φ4×28 90 ZSN4-280-21B 160
φ4×60m 2500 ZSN4-355-09Z 315
φ4.2×60m 2800 ZSN4-355-12 420
φ4.3×60m 3000 ZSN4-355-12 375
φ4.8×75m 5000 ZSN4-400-92 630





Note: Parameters should refer to the specific contract.
