Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining

Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining
Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining

Large Image :  Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: regular packing
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 300 sets per month
Detailed Product Description
Type: Rotary Drying Equipment Product Name: Steam Calcination Kiln
Material: Steel Keywords: Rotary Kiln
Color: Customizable Size: Customizable
Certification: ISO/CE Warranty: 1 Year
Applicable Industry: Energy & Mining Capacity: According To Different Types
High Light:

800TPD Steam Calcination Kiln

,

400TPD Steam Calcination Kiln

,

800TPD calcination rotary kiln

Customizable high productivity first-class Steam Calcination Kiln

Possessing the domestic first-class chemical kiln R&D team, perfect inspection means and large precise manufacturing equipments and technology, ZTIC has formed the perfect technology and production system of chemical kiln designing, manufacturing, installing and commissioning services.

Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining 0

Steam Calcination Kiln for Sodium Bicarbonate with Inner Recycling of Soda

Soda is an important fimdamental chemical product.The sodium bicarbonate’s calcination is one of the most important processesin soda production.in which the streanl calcinations kiIn is a key equipmem.

Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining 1

ZTIC Steam Calcination rotary kiln technical characteristics:
Kiln body is made of high quality composed of carbon steel or alloy steel plate and automatic welding;
Tyre,Support Roller,Open gear adopts alloy cast steel;
Sliding bearing with large gap not scraping tile bearing;
Transmission device adopts hard tooth surface reducer, flexible diaphragm coupling, dc motor;
Adopts hydraulic gear wheel;
Preheater scales were used respectively to veiw of kiln head, and cylinder pressure tight seal;
A slow drive device.



Customizable High Productivity 800TPD Steam Calcination Kiln Energy & Mining 2

  Unit Product specifications and parameter values
Φ2.5*27(m) Φ2.8*27(m) Φ3*30(m) Φ3.2*32(m)
Diameter mm Φ2500 Φ2800 Φ3000 Φ3200
Length mm 27000 27000 30000 32000
Main motor power kw 160 160 220 310
Kiln Body Main speed r/min 7 6.32 5.9 5.47
Slow speed 0.4 0.3 0.25 0.26
Steam passes Design pressure Mpa 3.53 3.53 3.53 3.53
Design temperature 270 270 270 270
Operating pressure MPa 3.2 3.2 3.2 3.2
Operating temperature 219 219 243 260
Case length Working pressure Mpa normal pressures
Working temperature 238 238 238 238
Heat transfer area m2 >2500 >3100 >3600 >4000
Capacity t/d 400 520 660 800
Installation Angle % 2 2) 2 2
Weight kg 198000 228000 300800 350000
Maximumfeed weight kg 250000 270000 350000
