Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone

China Luoyang Zhongtai Industrial Co., Ltd. certification
China Luoyang Zhongtai Industrial Co., Ltd. certification
I'm Online Chat Now

Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone

Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone
Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone

Large Image :  Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone

Product Details:
Place of Origin: China
Brand Name: ZTIC
Certification: ISO/CE
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: regular packing
Delivery Time: 1-2 months
Payment Terms: L/C, T/T
Supply Ability: 300 sets per month
Detailed Product Description
Type:: Impact Crusher Application:: Mining
Motor Type:: AC Motor Capacity(t/h):: 350 T/h
Feed Opening:: 1250x2030mm Max Feeding Size:: 600mm
Product Material:: High Hardness Stone Weight:: 40t
High Light:

350 T/H Portable Impact Crusher

,

Hardness Stone Portable Impact Crusher

,

350tph small impact crusher

advanced world standard impact crusher for high hardness stone



Description

ZTIC Impact Crusher with the advanced world standard, use the latest technology around the world. Because the rotor is the key part of the crusher and also the most critical part of inspection and acceptance, our company develops and produces the strong and heavy type rotor in order to get the higher rotary inertia. The use of high abrasion-resistant material and the best design of the crushing chamber make the performance of the crusher more remarkable.

Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone 0

Features

Wide feeding inlet, high crushing cavity, suitable for materials with high hardness and lumpiness, less stone powder and suitable for requirement of high-quality materials. Complete crushing function, high productivity, less consumption of machine parts and high comprehensive efficiency. Keyless connection, convenient maintenance, economical and reliable.

Advanced World Standard 350 t/h portable impact crusher For High Hardness Stone 1

Technical Parameters



Type
Feed Opening (mm)
Max. Feeding Edge (mm)
Capacity (t/h)
Power (kw)
Weight (kg)
PF-1010
400 x 1080
300
50-80
75
12200
PF-1210
400 x 1080
350
70-120
110
12500
PF-1214
400 x 1430
350
95-145
132
15300
PF-1315
800 x 1530
500
100-180
185
20800
PF-1420
1250 x 2030
600
350
355
40000
PF-1620
1600 x 2080
600-800
350-450
560
47500
