| Modle: | XB Serise Mixing Barrel | Condition: | New |
|---|---|---|---|
| Applicable: | Mining, Metallurgy, Pharmaceutical | Color: | Custom |
| Tank Diameter: | 70-3500 Mm | Weight: | 228-7110 Kg |
| Motor Power: | 1.1-22 Kw | Mixer Diameter: | 3240-850 Mm |
| Mixer Speed: | 200-530 R/min | Warranty: | 12 Months |
| Type: | Ore Dressing Equipment | Port: | QingDao,ShangHai,TianJin |
| High Light: | Mixing Barrel Ore Dressing Equipment,30m3 Ore Mixing Barrel,0.26m3 Ore Mixing Barrel |
||
XB Series Mixing Barrel Ore Dressing Equipment Mixing Machine Factory Price
1. Product description of stirring drum ore dressing equipment
The stirring barrel is the necessary equipment which is driven by the triangle belt of the motor to rotate the impeller, and fully mix the medicine and pulp evenly, increase the reaction time of the drug action and strengthen the quality of the drug reaction. This machine is suitable for the mining industry, but also can be used for various chemical industry tank mixing.
2. Product parameters of stirring drum ore dressing equipment
| Item | Internal dimensions of the tank | Effective volume(m³) | Mixer | Motor | Weight (kg) | |||
| Diameter(mm) | Depth(mm) | Diameter(mm) | Speed(r/min) | Model | Power (KW) | |||
| XB-750 | 750 | 750 | 0.26 | 240 | 530 | Y90S-4 | 1.1 | 228 |
| XB-1000 | 1000 | 1000 | 0.58 | 240 | 530 | Y90L-4 | 1.5 | 436 |
| XB-1200 | 1200 | 1200 | 1.14 | 400 | 320 | Y100L2-4 | 3 | 765 |
| XB-1500 | 1500 | 1500 | 2.2 | 400 | 320 | Y100L2-4 | 3 | 1083 |
| XB-2000 | 2000 | 2000 | 5.46 | 550 | 230 | Y132M2-6 | 5.5 | 1671 |
| XB-2500 | 2500 | 2500 | 11.2 | 650 | 200 | Y160L-6 | 11 | 3438 |
| XB-3000 | 3000 | 3000 | 19.1 | 700 | 210 | Y225S-8 | 18.5 | 4613 |
| XB-3500 | 3500 | 3500 | 30 | 850 | 230 | Y225M-8 | 22 | 7110 |
