OEM Lost Wax Precision Investment Casting Of Mining Parts

Precision Casting OEM Lost Wax Precision Investment Casting For Mining Parts

1. Mold precision casting technology can be used to manufacture various accessories and parts in the field of mining machinery to meet the special requirements of high strength, wear resistance, corrosion resistance and so on. Here are some examples of common mining machinery accessories:

(1) Grinding ball: used in the grinding process of grinding equipment, including grinding machines, ball mills, etc.

(2) Grinding lining plate: the lining plate used for grinding equipment to provide protection and support during the grinding process, such as the lining plate of the ball mill.

(3) Grinding rod: rod grinding for grinding equipment, providing crushing and grinding action, such as the grinding rod of the rod mill.

(4) Grinding cover body: the cover body used for grinding equipment to protect the environment and operator safety during the grinding process.

(5) Crusher accessories: including crusher tooth plate, hammer head, lining plate, etc., used for crushing ore and ore pretreatment.

(6) Conveyor accessories: such as conveyor rollers, conveyor belts, rollers, etc., used for processing and transporting ore and slag.

(7) flotation machine accessories: such as flotation machine tank body, agitator, bubble generator, etc., for the separation and flotation of ore flotation process.

(8) sand and stone sorting machine accessories: including screen, sorting plate, etc., used for sorting and screening ore and slag.

(9) magnetic separator accessories: such as magnetic roller of magnetic separator, magnetic bar, etc., for the magnetic separation process of ore.

These are just some examples of common accessories in the field of mining machinery, in fact, there are many other types of accessories and parts that can be manufactured by wax mold precision casting technology depending on the ore processing process and equipment type. The specific product category and application scope will be determined according to the needs of customers, design requirements and the characteristics of mining equipment.

Precision Casting OEM Lost Wax Precision Investment Casting For Mining Parts Castings And Forgings

2. Investment casting, also known as lost wax casting, wax casting or precision investment casting, is a casting process for manufacturing complex shapes and high-precision parts. The process typically includes the following steps:

(1) Mold manufacturing: First make molds according to product design requirements. Molds can be made of metal materials (such as aluminum alloy, steel, etc.) or refractory materials (such as gypsum, ceramics, etc.). Molds are used to make wax molds.

(2) Wax mold injection mold: melted wax material is injected into the mold to fill the mold cavity and form a wax mold similar to the final product.

(3) Wax mold assembly: a number of wax molds are assembled together to form a complete mold assembly, including feeding system, pouring system, etc.

(4) Vacuum dewaxing: the wax mold is placed in the vacuum dewaxing equipment, and the wax material in the wax mold is melted and evaporated by heating and vacuuming, so that the internal cavity of the wax mold becomes a cavity.

(5) Smelting metal: smelting appropriate metal alloys, usually using electric arc furnaces, induction furnaces or argon arc furnaces and other equipment for smelting.

(6) Casting injection: the preheated mold assembly is placed in the casting equipment, and the molten metal is injected into the mold cavity to fill the entire internal cavity of the wax mold.

(7) Cooling curing: After the metal is cooled and cured, the mold assembly is removed from the casting equipment.

(8) Mold crushing: the cooling solidified metal parts are separated from the mold, and the mold is often broken by mechanical or chemical methods to obtain the final casting.

(9) Finishing processing: finishing, removing residual material, deburring and other processing processes on the casting to obtain the final product that meets the requirements.

Investment casting process is suitable for the manufacture of complex, high-precision, high-quality parts, commonly used in aerospace, aviation engines, automobiles, medical equipment, electronics and other fields. It enables the production of parts with complex shapes, small structures and precise dimensions.

Precision Casting OEM Lost Wax Precision Investment Casting For Mining Parts Castings And Forgings

3. Table examples of common parameters of die casting products:
