Low Operating Cost XHP Multi-Cylinder Hydraulic Cone Crusher For Crushable Basalt

Large Image : Low Operating Cost XHP Multi-Cylinder Hydraulic Cone Crusher For Crushable Basalt

Product Details:

Place of Origin:	Henan, China
Brand Name:	ZTIC
Certification:	ISO/CE
Model Number:	Stone Crusher Machine

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set/Sets
Price:	negotiate
Payment Terms:	L/C, T/T
Supply Ability:	5000 Set/Sets per Year

Contact Now

Detailed Product Description

Name:	Multi-Cylinder Hydraulic Cone Crusher	Application:	Stones And Bulk Materials Crushing
Model:	XHP Multi-Cylinder Hydraulic Cone Crusher	Total Weight(t):	14-380
Capacity:	90-1200	Classification:	Stone Crusher Machine
Place Of Origin:	Luoyang, China	Warranty:	12 Months
Highlight:	Multi-Cylinder Hydraulic Cone Crusher , Hydraulic Cone Crusher , Crushable Basalt Hydraulic Cone Crusher

Low Operating Cost XHP Multi-cylinder Hydraulic Cone Crusher for Crushable Basalt

Overview

Production capacity: 3-500T/H
Feed size: ≤1020MM
Applicable materials: The XHP cone crusher not only improves production capacity and crushing efficiency but also expands its application range, from limestone to basalt, from stone production to various ore crushing, completing various medium, fine, and ultra-fine crushing operations.
Application fields: Widely used in stone production, artificial sand making, ore dressing production, etc.

Product Introduction Of Stone Crusher Machine

The XHP hydraulic cone crusher is advanced cone crushing equipment. Different from previous cone crushers, it adopts a multi-cylinder design at the bottom, which improves production efficiency. Its internal structure design and the application of wear-resistant materials enable it to crush hard rocks like basalt and various hard ore minerals, widely used in stone production, artificial sand making, ore dressing production, and other operations.

Product Advantages Of Stone Crusher Machine

(1) High crushing ratio and production efficiency

(2) Low wear parts consumption and operating costs

(3) Hydraulic protection and clearing, high automation, reduced downtime

(4) Dilute oil lubrication, reliable and advanced, extended service life

(5) Multi-cylinder crushing cavity, flexible application, strong adaptability

(6) Excellent production efficiency

Product parameters Of Stone Crusher Machine

Model	Cavity	Standard		Short head type		power(kw)	capacity	The host weight(t)	Total weight(t)
Model	Cavity	Feeding Size(MM)	Discharging Size(MM)	Feeding Size(MM)	Discharging Size(MM)	power(kw)	capacity	The host weight(t)	Total weight(t)
XHP200	(BC)					132-200	90-250	11.14	14
	(C)	185	19	76	10
	(m)	125	17	54	6
	(F)	95	13	23	6
	(BF)			10	5
XHP300	(BC)	230	25			180-250	110-440	15.8	19.96
	(C)	210	20	75	10
	(m)	150	15	50	8
	(F)	105	10	20	6
	(BF)			20	6
XHP400	(BC)	295	30			280-355	140-630	23	28.72
	(C)	250	25	90	10
	(m)	195	20	50	8
	(F)	110	14	40	6
	(BF)			30	6
XHP500	(BC)	330	30			355-450	175-790	33.3	38
	(C)	285	25	90	13
	(m)	200	20	55	10
	(F)	133	16	40	8
	(BF)			35	6
XHP800	(BC)	353	32			550-630	260-1200
	(C)	297	32	155	13
	(m)	267	25	92	10
	(F)	219	16	33	6
	(BF)

Low Operating Cost XHP Multi-Cylinder Hydraulic Cone Crusher For Crushable Basalt 0

Low Operating Cost XHP Multi-Cylinder Hydraulic Cone Crusher For Crushable Basalt 1
