Stone Crusher Machine Cone Crusher With Large Reduction Ratio Good Particle For Mining
1. Stone Crusher Machine Mining Cone Crusher Introduction
Cone crusher is the core secondary and fine crushing equipment in the mining and aggregate processing industries. Based on the laminated crushing principle, it realizes extrusion and grinding of ores through the relative movement between the moving cone and the fixed cone. It features high crushing efficiency and excellent final particle shape. Compact in structure and large in crushing ratio, it is specially designed for high-hardness and high-abrasion materials such as granite, basalt and iron ore. It is the key equipment for large-scale mining production and aggregate upgrading, suitable for open-pit mines, underground mines and quarries.
2. Stone Crusher Machine Mining Cone Crusher Advantages
High efficiency and large output, with higher crushing ratio and lower energy consumption.
Wear-resistant parts made of high-strength alloy steel, long service life, low operation cost.
Intelligent hydraulic adjustment system, easy to control discharge size and maintain.
Excellent cubic particle shape, low needle flake content, meeting high-grade aggregate standards.
Stable performance with iron-passing protection, supporting 24-hour continuous operation.
3. Stone Crusher Machine Mining Cone Crusher Technical Parameters
| Model |
Feed opening |
Max feed |
Discharge size |
Capacity |
Motor |
Weight |
| (mm) |
size(mm) |
(mm) |
(T/H) |
(KW) |
(T) |
| PYB-600 |
75 |
65 |
12-15 |
40 |
30 |
5 |
| PYD-600 |
40 |
35 |
3-13 |
12-23 |
30 |
5.1 |
| PYB-900 |
135 |
115 |
15-50 |
50-90 |
55 |
11.2 |
| PYZ-900 |
70 |
60 |
5-20 |
20-65 |
55 |
11.2 |
| PYD-900 |
50 |
40 |
3-13 |
15-50 |
55 |
11.3 |
| PYB-1200 |
170 |
145 |
20-50 |
110-168 |
110 |
24.7 |
| PYZ-1200 |
115 |
100 |
8-25 |
42-135 |
110 |
25 |
| PYD-1200 |
60 |
50 |
3-15 |
18-105 |
110 |
25.3 |
| PYB-1750 |
250 |
215 |
25-50 |
280-480 |
160 |
50.3 |
| PYZ-1750 |
215 |
185 |
10-30 |
115-320 |
160 |
50.3 |
| PYD-1750 |
100 |
85 |
5-15 |
75-230 |
160 |
50.2 |
| PYB-2200 |
350 |
300 |
30-60 |
590-1000 |
280/260 |
80 |
| PYZ-2200 |
275 |
230 |
10-30 |
200-580 |
280/260 |
80 |
| PYD-2200 |
130 |
100 |
5-16 |
120-340 |
280/260 |
81.4 |
4. Inquiry & Purchase
We are a direct manufacturer of mining machinery with complete models, sufficient stock and strong customization ability. We provide professional installation, commissioning and after-sales service.
Whether you are expanding production for a small mine or upgrading equipment for a large aggregate plant, we can provide the most suitable crushing solution. Welcome to contact us for detailed parameters, quotation and site inspection.
