Product Details:
Payment & Shipping Terms:
|
| Application: | Hydropower Plant | Capacity Power: | 150kw |
|---|---|---|---|
| Voltage: | 400v | Rotating Speed: | 86.6 R/min |
| Frequency Of Generator: | 50Hz | Model: | Generator |
| Max Hydraulic Thrust Pt: | 1.72 T | Type: | Power Generation Equipment |
| Generator Type: | SFWE-W150-12/850 | Keyword: | Hydro Power Turbine |
| Name: | 150kw Francis Turbine Generator Unit | Warranty: | 12 Month |
| High Light: | Hydro Turbine Power Generation Equipment,150kw Francis Hydro Turbine Generator,150kw Hydro Turbine Generator Unit |
||
Power Generation Equipment Hydro Turbine Generator 150kw Francis Turbine Generator Unit
1. About us
Luoyang Zhongtai Industries CO.,LTD is focused on design and manufacturing hydro turbines.
The company was founded in 2014. Luoyang Zhongtai strictly abides by IEC international standards and national standards. And has CE, ISO,TUV,SGS certificates. In the management system, we still adhere to the rigorous work style formed in the turbine industry for many years, and continuously improve and improve the management system of the enterprise. We have been increasing our technical strength and equipment investment, focusing on the production, manufacture and installation of hydro-generator equipment, power station auxiliary equipment and various components. We always provide customers with technical advice, services and the best technical solutions based on customer parameters. At the same time, we provide continuous after-sales service for our products. Adhere to honesty and pragmatism, quality first, broad mind, and invest in our work with a life attitude, and strive to create a win-win situation for customers, enterprises and society.
Power Generation Equipment Hydro Turbine Generator 150kw Francis Turbine Generator Unit
2. Technical Parameters
| Product name: 150kw Francis Turbine Generator Unit | |||
| Technical Parameters | |||
| Net Head: | Hr | 12 | m |
| Design flow | Qr | 1.56 | m3/s |
| Capacity Power | P | 150 | kw |
| Turbine | Generator | ||
| Model | HLA551-WJ-64 | Model | SFWE-W150-12/850 |
| Unit Flow Q11 | 1.248m3/s | Rated Efficiency of Generator ηf | 94% |
| Unit Rotating Speed n11 | 86.6r/min | Frequency of the | 50Hz |
| Max Hydraulic Thrust Pt | 1.72t | Rated voltage of | 400V |
Rated rotating speed | 500r/min | Rated current of the generator I | 289A |
Efficiency of turbine | 93.5% | Excitation | Brushless Excitation |
Max Runway speed | 910r/min | Connection way | Direct Connect |
| Rated Output Nt | 168kW | Max runaway speed | 1000r/min |
| Rated Discharge Qr | 1.56m3/s | Rated rotating speed nr | 500r/min |
Turbine real machine efficiency ηr | 89% | Unit support form | Horizontal 2 point |
Power Generation Equipment Hydro Turbine Generator 150kw Francis Turbine Generator Unit
